10-08-5071

厂商：
MOLEX1
封装：
描述：
10-08-5071 - 5.08mm (.200") Pitch KK® Header, Vertical, with Polarizing Backwall, 7 Circuits, Tin (S...

数据手册：

下载10-08-5071.pdf

立即购买

详情介绍
数据手册
价格&库存

10-08-5071 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010085071 Active kk 5.08mm (.200") Pitch KK® Header, Vertical, with Polarizing Backwall, 7 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification UL General Product Family Series Application Overview Product Name PCB Headers 2599 Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 7 7 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.175 In 4.45 mm None 0.062 In 1.60 mm Bag 0.200 In 5.08 mm 200 5 200 5 No Partial Yes No 0°C to +75°C Through Hole Search Parts in this Series 2599Series Mates With KK® Crimp Housing 3001 , 5058. 3002 KK® PC Board Connector Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 2599M-07A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-2599M-N* This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

10-08-5071

1. 物料型号： - 型号：0010085071 - 状态：Active（活跃）

2. 器件简介： - 描述：5.08mm (.200") 间距KK® 垂直头，带极化后壁，7电路，镀锡。

3. 引脚分配： - 电路（已加载）：7 - 最大电路数：7

4. 参数特性： - 颜色 - 树脂：自然色 - 耐久性（最大插拔次数）：25次 - 阻燃等级：94V-2 - 金属材质：黄铜 - 镀层 - 插接：锡 - 镀层 - 终止：锡 - 树脂材质编号：尼龙 - 方向：垂直 - PCB尾长（英寸）：0.175英寸 - PCB尾长（毫米）：4.45毫米 - PCB厚度推荐（英寸）：0.062英寸 - PCB厚度推荐（毫米）：1.60毫米 - 间距 - 插接界面（英寸）：0.200英寸 - 间距 - 插接界面（毫米）：5.08毫米 - 极化到PCB：否 - 部分屏蔽 - 可堆叠：是

5. 功能详解： - 产品名称：KKR - 物理特性：无断路 - 温度范围 - 操作：0°C至+75°C - 终止接口样式：通孔

6. 应用信息： - 产品家族：PCB头 - 系列：2599 - 应用：线对板

7. 封装信息： - 包装类型：袋装 - 表面贴装兼容（SMC）：否
