This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010101111 Active kk 5.08mm (.200") Pitch KK® PC Board Connector, Right Angle Mount Style A, 1.0µm (40µ") Tin (Sn), 11 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Receptacles 3002 Board-to-Board kk KK® Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Temperature Range - Operating Termination Interface: Style 11 Natural 25 94V-2 No Phosphor Bronze Tin Tin Nylon 1 Right Angle 0.169 In 4.30 mm No Yes 0.062 In 1.60 mm Tray 0.200 In 5.08 mm 40.00 1.000 40.00 1.00 Yes 0°C to +75°C Through Hole Search Parts in this Series 3002Series Mates With 3003 , 2599 , 3008 Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 300211A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3002-NA-* This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
