10-18-1122

This document was generated on 04/20/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0010181122 Active 2.36mm (.093") Diameter Standard .093" Pin and Socket Header, 3 Rows, Shrouded, Unfilled Polyester, UL 94V-0, 12 Circuits, 12 Female Terminals Documents: 3D Model Drawing (PDF) RoHS Certificate of Compliance (PDF) General Product Family Series Application Comments Product Name PCB Headers 3099 Wire-to-Board Solder Type, Round Socket Standard .093" Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Breakaway Circuits (Loaded) Circuits (maximum) Circuits Detail Color - Resin Durability (mating cycles max) First Mate / Last Break Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 12 12 12 Female Socket Contacts Black 25 No No No None Yes Phosphor Bronze Tin Tin Polyester 3 Vertical 0.170 In 4.32 mm Yes None 0.062 In 1.60 mm Bag 0.198 In 5.03 mm 50 1.25 50 1.25 Yes Yes Fully No No -40°C to +105°C Through Hole Search Parts in this Series 3099Series Mates With 03-09-1125 , 03-09-1126 Electrical Current - Maximum per Contact Voltage - Maximum 5A 250V Material Info Old Part Number A30991203 Reference - Drawing Numbers Sales Drawing SDA-3099-12** This document was generated on 04/20/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
