10-45-1031

厂商：
MOLEX1
封装：
描述：
10-45-1031 - 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 3 Circuits, Gold (Au) Plating,Pin...

数据手册：

下载10-45-1031.pdf

立即购买

详情介绍
数据手册
价格&库存

10-45-1031 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010451031 Active kk 5.08mm (.200") Pitch KK® Header, Vertical, Round Pin, 3 Circuits, Gold (Au) Plating, Pin Length 19.05mm (.750") Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Headers 3003 Board-to-Board, Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB No 3 3 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.155 In 3.94 mm No None 0.062 In 1.60 mm Bag 0.200 In 5.08 mm 0.200 In 5.08 mm 20 .5 30 .76 No No Search Parts in this Series 3003Series Mates With KK® Crimp Terminal Housing 3001 , 5058 Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No No No 0°C to +50°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 3003-03AG Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3003-N* This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

10-45-1031

1. 物料型号： - 型号：0010451031 - 状态：Active（活跃）

2. 器件简介： - 描述：5.08mm (.200") 间距 KK@ 垂直式头，圆针，3路，引脚长度19.05mm (.750")。 - 文档：包括3D模型图纸（PDF）、产品规格PS-99020-（RoHS合规证书）。

3. 引脚分配： - 电路（已加载）：3路 - 最大电路数：3路 - 引脚数：1排

4. 参数特性： - 耐环境性：无卤素，符合EU RoHS、中国RoHS、ELV和RoHS标准，REACH SVHC未审核。 - 耐久性（最大插拔次数）：25次 - 阻燃性：94V-2 - 引脚材料：黄铜，镀锡

5. 功能详解： - 产品系列：3003 - 应用：板对板、线对板连接 - 物理特性：不可分离，最大25次插拔，自然色树脂，无极性，无锁扣。

6. 应用信息： - 配合KK®压接端子座3001、5058使用。 - 工作温度范围：0℃至+50℃。 - 电气特性：最大电流每接触点7A，最大电压250V。

7. 封装信息： - 封装类型：袋装。 - 推荐PCB厚度：0.062英寸（1.60毫米）。 - 引脚间距：5.08mm（0.200英寸）。 - 引脚长度：19.05mm（0.750英寸）。
