This document was generated on 05/24/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number: Status: Overview: Description:
0010455111 Active
kk 5.08mm (.200") Pitch KK® Header, Vertical, with Polarizing Backwall, 11 Circuits, Gold (Au) Plating
Documents: 3D Model Drawing (PDF)
Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions.
Agency Certification
UL
General
Product Family Series Application Overview Product Name PCB Headers 2599 Wire-to-Board kk KK®
Physical
Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 11 11 Natural 50 No 94V-2 No No None None Brass Gold Gold Nylon 1 Vertical 0.175 In 4.45 mm None 0.062 In 1.60 mm Bag 0.200 In 5.08 mm 20 0.5 20 0.5 No Partial Yes No 0°C to +75°C Through Hole
Search Parts in this Series 2599Series Mates With KK® Crimp Terminal Housing 3001 , 5058
Electrical
Current - Maximum per Contact Voltage - Maximum 7A 250V
Material Info
Old Part Number 2599M11AG
Reference - Drawing Numbers
Product Specification Sales Drawing PS-99020-0087 SDAE-2599M-N*
