Part Number: Status: Overview: Description:
0010634057 Active
kk 7.92mm (.312") Pitch SPOX™ Header, Vertical, with Friction Lock, 5 Circuits
Documents: 3D Model Drawing (PDF) Product Specification PS-5195-002 (PDF)
Product Specification PS-5195-006 (PDF) Product Specification PS-5239-005 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 R72090224 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions.
Agency Certification
CSA TUV
General
Product Family Series Application Overview Product Name PCB Headers 5096 Wire-to-Board kk SPOX™
Physical
Breakaway Circuits (Loaded) Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Temperature Range - Operating Termination Interface: Style No 5 30 No 94V-2 No No None Yes Brass Tin Tin Nylon 1 Vertical 0.142 In 3.60 mm No None 0.062 In 1.60 mm Bag 0.312 In 7.92 mm 200 5 200 5 No Partial No -40°C to +105°C Through Hole
Search Parts in this Series 5096Series Mates With 5195 SPOX™ Crimp Housing. 5239 KK® Crimp Housing
Electrical
Current - Maximum per Contact Voltage - Maximum 7A 250V
Material Info
Old Part Number 5096-05C
Reference - Drawing Numbers
Packaging Specification Product Specification Sales Drawing SPK-5096-001 PS-5195-002, PS-5195-006, PS-5239-005 SD-5096-001
