10-84-4020

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0010844020 Active mlx 6.35mm (.250) Pitch MLX™ Power Connector Header, Vertical, 2 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, White Documents: 3D Model Drawing (PDF) Product Specification PS-42022-0001 (PDF) Product Specification PSX-42002-0001 (PDF) Product Specification PSX-42002-0002 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only Series Agency Certification CSA UL LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Comments Overview Product Name PCB Headers 42002 Wire-to-Board Solder Type mlx MLX™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to PCB Shrouded Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 2 2 Natural 50 No 94V-2 No Yes Yes Yes Phosphor Bronze Tin Nylon 1 Vertical 0.168 In 4.27 mm Yes 0.125 In 1.60 mm Bag 0.250 In 6.35 mm Yes Fully No -55°C to +105°C Through Hole Search Parts in this Series 42002Series Mates With 42021 Plug Electrical Current - Maximum per Contact 13.5A Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Process Temperature max. C 10 Wave Capable (TH only) 260 Material Info Old Part Number A-42002-2A1A1 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-43255-001 PS-42022-0001, PSX-42002-0001, PSX-42002-0002 SDA-42002-***** This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
