14-45-1811

厂商：
MOLEX1
封装：
描述：
14-45-1811 - 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Male, Single Row, ...

数据手册：

下载14-45-1811.pdf

立即购买

详情介绍
数据手册
价格&库存

14-45-1811 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0014451811 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Male, Single Row, Version D, Back Ribs, for Wire Size 28, 3.81µm (150µ") Tin (Sn), 11 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70400 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only LR19980 E29179 EU RoHS China RoHS Compliance Status Not Reviewed REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series Agency Certification CSA UL General Product Family Series Comments Component Type Glow-Wire Compliant Overview Product Name Ribbon Cable / Wire Trap Connectors 70475 Terminals Preloaded Housing No cgrid__sl_products SL™ Physical Circuits (Loaded) Durability (mating cycles max) Entry Angle Flammability Lock to Mating Part Number of Rows PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to Mating Part Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Wire Insulation Diameter Wire Size AWG Wire/Cable Type 11 25 Vertical 94V-0 None 1 None Tube 0.100 In 2.54 mm No Yes N/A -40°C to +105°C 1.35mm (.053") max. 28 Discrete Wire, Ribbon Cable Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Search Parts in this Series 70475Series Mates With 70004 Interim Clip (Single Row), 70013 Interim Clip (Dual Row) Use With 7307 Tinned 28AWG, 7767 Topcoat 28AWG, 24241 Tinned 26AWG, 8996 Topcoat 26AWG, 24226 Tinned 24AWG, 8997 Topcoat 24AWG, 24369 High Flex 26AWG, 24389 High Flex 24AWG Electrical Current - Maximum per Contact Voltage - Maximum 1.2A 250V Material Info Reference - Drawing Numbers Product Specification PS-70400 This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

14-45-1811

1. 物料型号： - 零件编号：0014451811 - 状态：激活

2. 器件简介： - 产品描述：2.54mm（.100"）间距SL™绝缘位移连接器组件，男性，单排，版本D，背部肋骨，适用于线径28，3.81µm（150µ"）锡（Sn），11电路。 - 产品规格：PS-70400（PDF） - RoHS合规证书（PDF）

3. 引脚分配： - 电路（已加载）：11

4. 参数特性： - 耐久性（最大插拔次数）：25 - 进入角度：垂直 - 阻燃性：94V-0 - 排数：1 - 引脚间距-配合接口（英寸）：0.100英寸 - 引脚间距-配合接口（毫米）：2.54毫米 - 操作温度范围：-40°C至+105°C - 线绝缘直径：1.35mm（.053"）最大 - 线规AWG：28 - 电线/电缆类型：离散线，扁平电缆

5. 功能详解： - 产品名称：SLTM - 物理特性：垂直进入角度，单排，无极性配合，可堆叠 - 电气特性：每个接触点最大电流1.2A，最大电压250V

6. 应用信息： - 与70004单排临时夹、70013双排临时夹配合使用 - 与7307镀锡28AWG、7767顶涂层28AWG、24241镀锡26AWG、8996顶涂层26AWG、24226镀锡24AWG、8997顶涂层24AWG、24369高柔26AWG、24389高柔24AWG等线缆配合使用

7. 封装信息： - 包装类型：管装
