14-56-3232

厂商：
MOLEX1
封装：
描述：
14-56-3232 - 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row...

数据手册：

下载14-56-3232.pdf

立即购买

详情介绍
数据手册
价格&库存

14-56-3232 数据手册

This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0014563232 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row, Version A, Nonpolarized, Wire Size 28, 0.76µm (30µ") Gold (Au), 23 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70400 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only Series Agency Certification CSA UL LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Comments Component Type Glow-Wire Compliant Overview Product Name Ribbon Cable / Wire Trap Connectors 70400 Terminals Preloaded Housing No cgrid__sl_products SL™ Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Entry Angle Flammability Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire/Cable Type 23 Black 50 Vertical 94V-0 None Phosphor Bronze Gold Tin Polyester Alloy 1 None Tube 0.100 In 2.54 mm 30 0.75 75 1.875 No Yes N/A -40°C to +105°C IDT or Pierce 1.35mm (.053") max. 28 Discrete Wire, Ribbon Cable Search Parts in this Series 70400Series Mates With Single Row headers and housings, 8624 , 70203 , 42375 , 42377 Use With 7307 Tinned 28AWG, 7767 Topcoat 28AWG, 24241 Tinned 26AWG, 8996 Topcoat 26AWG, 24226 Tinned 24AWG, 8997 Topcoat 24AWG, 24369 High Flex 26AWG, 24389 High Flex 24AWG Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hawk Semi0011201337 Automatice Discrete Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Material Info Reference - Drawing Numbers Product Specification Sales Drawing PS-70400 SDA-70400-1401-1424 Wire Terminator for SL - Rebuilt US* Hawk™ Ribbon Cable Terminator for SL without Break-off Hawk™ SemiAutomatic Discrete Wire Terminator for SL - Rebuilt CE Approved* Hawk™ Flat Flex Cable Terminator for SL with Break-off Hawk™ Ribbon Cable Terminator with for SL Break-off IDT Discrete Handtool Module for SL™ Hawk™ SemiAutomatic Discrete Wire Terminator for SL 0623003000 0623004900 0623005200 0623005300 0621000700 0623003100 This document was generated on 05/21/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

14-56-3232

1. 物料型号： - 型号：0014563232 - 状态：Active（活跃）

2. 器件简介： - 描述：2.54mm（.100"）Pitch SL™绝缘位移连接器组件，女性端， - 符合欧盟RoHS、中国RoHS、ELV和RoHS标准，REACH SVHC未审核，卤素状态未审核。

3. 引脚分配： - 单排，版本A，非极性，线规28AWG，0.76um（30"）G电路。

4. 参数特性： - 电路（已加载）：23 - 树脂颜色：黑色 - 耐久性（最大插拔次数）：50 - 进入角度：垂直 - 阻燃性：94V-0 - 金属材质：磷青铜 - 镀层材质：接触部位金镀层，终止部位锡镀层 - 树脂材质：聚酯合金 - 行数：单行 - PCB固定：无 - 包装类型：管装 - 插接界面间距（英寸）：0.100 In - 插接界面间距（毫米）：2.54 mm - 镀层最小厚度：接触部位30um，终止部位75um - 极性：非极性 - 堆叠：是 - 表面贴装兼容（SMC）：不适用 - 工作温度范围：-40°C至+105°C - 接线端界面样式：IDT或刺穿式 - 线绝缘直径：最大1.35mm(.053")。 - 线规AWG：28 - 线/电缆类型：离散线，扁平电缆。

5. 功能详解： - 最大电流每接触点：3A - 最大电压：250V

6. 应用信息： - 与单排头和外壳8624、70203、42375、42377配合使用。 - 与7307镀锡28AWG、7767顶涂层28AWG、24241镀锡26AWG、8996顶涂层26AWG、24226镀锡24AWG、8997顶涂层24AWG、24369高柔26AWG、24389高柔24AWG线缆配合使用。

7. 封装信息： - 封装类型：管装 - 间距：2.54mm（0.100"）
