14-60-0104

厂商：
MOLEX1
封装：
描述：
14-60-0104 - 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row...

数据手册：

下载14-60-0104.pdf

立即购买

详情介绍
数据手册
价格&库存

14-60-0104 数据手册

This document was generated on 03/30/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0014600104 Active 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row, Version G, Positive Lock, Wire Size 26, 3.81µm (150µ") Tin/Lead (SnPb), 10 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70400 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Comments Component Type Glow-Wire Compliant Product Name Ribbon Cable / Wire Trap Connectors 70400 Terminals Preloaded Housing No SL™ Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Entry Angle Flammability Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire/Cable Type 10 Black 25 Vertical 94V-0 Yes Phosphor Bronze Tin Tin Polyester Alloy 1 None Tube 0.100 In 2.54 mm 150 3.75 75 1.875 Yes Yes N/A -40°C to +105°C IDT or Pierce 1.35mm (.053") max. 26 Discrete Wire, Ribbon Cable Search Parts in this Series 70400Series Mates With 70018 , 70107A/B, 70543, 70545 , 70553 , 70555 Use With 7307 Tinned 28AWG, 7767 Topcoat 28AWG, 24241 Tinned 26AWG, 8996 Topcoat 26AWG, 24226 Tinned 24AWG, 8997 Topcoat 24AWG, 24369 High Flex 26AWG, 24389 High Flex 24AWG Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hawk Semi0011201337 Automatice Discrete Electrical Current - Maximum per Contact Voltage - Maximum 1.8A 250V Material Info Old Part Number 70400-0324 Reference - Drawing Numbers Product Specification Sales Drawing PS-70400 SDA-70400-0316-0339 Wire Terminator for SL - Rebuilt US* Hawk™ Ribbon Cable Terminator for SL without Break-off Hawk™ SemiAutomatic Discrete Wire Terminator for SL Hawk™ Flat Flex Cable Terminator for SL with Break-off Hawk™ Ribbon Cable Terminator with for SL Break-off Hawk™ SemiAutomatic Discrete Wire Terminator for SL - Rebuilt CE Approved* 0623003000 0623003100 0623005200 0623005300 0623004900 This document was generated on 03/30/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

14-60-0104

1. 物料型号： - 型号：0014600104 - 描述：2.54mm (.100") 间距 SL™ 绝缘位移连接器组件，女性，单排，版本G，正锁定，线径26，3.81µm (150µ") 锡/铅 (SnPb)。

2. 器件简介： - 产品系列：70400 - 组件类型：Housing - 产品名称：SLTM - 电路（已加载）：10 - 颜色 - 树脂：黑色 - 耐久性（最大插拔次数）：25 - 进入角度：垂直 - 阻燃性：94V-0 - 锁到配对部件：是 - 金属材质：磷青铜 - 配对金属镀层：锡 - 终止金属镀层：锡 - 树脂材质：聚酯合金 - 行数：1 - PCB保持：无 - 包装类型：管

3. 引脚分配： - 引脚数量：10个电路

4. 参数特性： - 每个接触点最大电流：1.8A - 最大电压：250V - 工作温度范围：-40°C至+105°C - 终止接口样式：IDT或刺穿

5. 功能详解： - 该连接器组件具有正锁定机制，确保连接的稳定性。 - 适用于26AWG线径的电线，可以是离散线或扁平电缆。

6. 应用信息： - 与70018、70107A/B、70543、70545、70553、70555等型号相匹配。 - 可与多种类型的电线配合使用，如7307镀锡28AWG、7767顶涂层28AWG等。

7. 封装信息： - 间距 - 配对接口（英寸）：0.100 In 2.54 mm - 镀层最小：配对（微英寸）：150 - 镀层最小：配对（微米）：3.75 - 镀层最小：终止（微米）：1.875
