14-60-0255

厂商：
MOLEX1
封装：
描述：
14-60-0255 - 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row...

数据手册：

下载14-60-0255.pdf

立即购买

详情介绍
数据手册
价格&库存

14-60-0255 数据手册

This document was generated on 03/30/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0014600255 Active 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row, Version A, Nonpolarized, Wire Size 28, 3.81µm (150µ") Tin/Lead (SnPb), 25 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70400 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Comments Component Type Glow-Wire Compliant Product Name Ribbon Cable / Wire Trap Connectors 70400 Terminals Preloaded Housing No SL™ Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Entry Angle Flammability Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire/Cable Type 25 Black 25 Vertical 94V-0 None Phosphor Bronze Tin Tin Polyester Alloy 1 None Tube 0.100 In 2.54 mm 150 3.75 75 1.875 No Yes N/A -40°C to +105°C IDT or Pierce 1.35mm (.053") max. 28 Discrete Wire, Ribbon Cable Search Parts in this Series 70400Series Mates With Single Row headers and housings, 8624 , 70203 , 42375 , 42377 Use With 7307 Tinned 28AWG, 7767 Topcoat 28AWG, 24241 Tinned 26AWG, 8996 Topcoat 26AWG, 24226 Tinned 24AWG, 8997 Topcoat 24AWG, 24369 High Flex 26AWG, 24389 High Flex 24AWG Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hawk Semi0011201337 Automatice Discrete Electrical Current - Maximum per Contact Voltage - Maximum 1.2A 250V Material Info Reference - Drawing Numbers Product Specification Sales Drawing PS-70400 SDA-70400-0351-0374 Wire Terminator for SL - Rebuilt US* Hawk™ Ribbon Cable Terminator for SL without Break-off Hawk™ SemiAutomatic Discrete Wire Terminator for SL Hawk™ Flat Flex Cable Terminator for SL with Break-off Hawk™ Ribbon Cable Terminator with for SL Break-off Hawk™ SemiAutomatic Discrete Wire Terminator for SL - Rebuilt CE Approved* 0623003000 0623003100 0623005200 0623005300 0623004900 This document was generated on 03/30/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

14-60-0255

1. 物料型号： - 型号：0014600255 - 描述：Active 2.54mm (.100") Pitch SL™ Insulation Displacement Connector Assembly, Female, Single Row, Version A, Nonpolarized, Wire Size 28, 3.81µm (150µ") Tin/Lead (SnPb), 25 Circuits

2. 器件简介： - 产品家族：Ribbon Cable / Wire Trap Connectors - 系列：70400 - 评论：Terminals Preloaded - 组件类型：Housing - 物理特性：25个电路，黑色树脂，最大25次插拔寿命，垂直进入角度，94V-0阻燃等级，单排1行，包装类型为管装。

3. 引脚分配： - 引脚数量：25 - 引脚间距：2.54mm (0.100 in)

4. 参数特性： - 耐温范围：-40°C至+105°C - 接触最大电流：1.2A - 最大电压：250V - 导线规格：28 AWG - 导线/电缆类型：Discrete Wire, Ribbon Cable

5. 功能详解： - 该连接器支持IDT或Pierce式端子接口，适用于单排针头和外壳，与多种类型的导线兼容，如7307 Tinned 28AWG等。

6. 应用信息： - 与多种单排针头和外壳兼容，如8624、70203、42375、42377等。 - 可与多种类型的导线配合使用，如7767 Topcoat 28AWG、24241 Tinned 26AWG等。

7. 封装信息： - 封装类型：Tube - 引脚间距：2.54mm (0.100 in) - 金属材质：磷青铜 - 金属镀层：锡 - 树脂材质：Polyester Alloy
