15-06-0046

This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015060046 Active minifit_bmi 4.20mm (.165") Pitch Mini-Fit BMI™ Plug Housing, Dual Row with Panel Mount Ears, PA Polyamide Nylon 6/6, UL 94V-0, 4 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-5556-002 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Comments Crimp Housings 42475 Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 series terminals crimped to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current derating information. minifit_bmi Mini-Fit BMI™ Overview Product Name Physical Circuits (maximum) Color - Resin Flammability Gender Glow-Wire Compliant Lock to Mating Part Material - Resin Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to Mating Part Stackable Temperature Range - Operating 4 Natural 94V-0 Male No None Nylon 2 Bag Yes 0.165 In 4.20 mm Yes No -40°C to +105°C Search Parts in this Series 42475Series Mates With 15-06-0041 Mini-Fit BMI Panel Mount Receptacle, 42385 Mini-Fit BMI 4 Circuit, UL 94V-0 Vertical Receptacle Headers, 44475-0421 Mini-Fit BMI HCS Vertical Receptacle Header Use With 46012 Mini-Fit Plus HCS™ Crimp Terminal, 5558 Mini-Fit™ Crimp Terminal Electrical Current - Maximum per Contact 13A Material Info Old Part Number 42475-0421 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing Test Summary PK-42474-001 PS-5556-002 SD-42475-***1 TS-5556-002 This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
