15-28-6041

厂商：
MOLEX1
封装：
描述：
15-28-6041 - 4.20mm (.165") Pitch Mini-Fit BMIâ„¢ Header, Dual Row, Vertical, with Snap-in Plastic P...

数据手册：

下载15-28-6041.pdf

立即购买

详情介绍
数据手册
价格&库存

15-28-6041 数据手册

This document was generated on 05/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0015286041 Active 4.20mm (.165") Pitch Mini-Fit BMI™ Header, Dual Row, Vertical, with Snap-in Plastic Peg PCB Lock, 4 Circuits, PA Polyamide Nylon 6/6, UL 94V-2, Select Gold (Au) Plating, without Drain Holes Documents: 3D Model Drawing (PDF) Product Specification PS-5556-002 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 R72082037 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA TUV UL General Product Family Series Application Comments PCB Headers 42440 Board-to-Board, Wire-to-Board Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 Mini-Fit Plus HCS™ Crimp Terminal Crimpted to to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current de-rating information.. High Temperature, Square Pin, Solder Type Mini-Fit BMI™ Product Name Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) No 4 4 Natural 30 94V-2 No Yes Yes Brass Gold Tin Nylon 2 Vertical 0.140 In 3.56 mm Yes Yes 0.070 In 1.80 mm Tray 0.165 In 4.20 mm 30 0.76 100 2.50 Search Parts in this Series 42440Series Mates With 15-06-0040 Mini-Fit BMI™ Panel Mount Receptacle, 39-01-3042 Mini-Fit Jr.™ Receptacle, 15-24-7042 Mini-Fit BMI™ Vertical Receptacle Header Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Yes Yes Partial No No -40°C to +105°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 13A 600V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 Wave Capable (TH only) 1 240 Material Info Old Part Number A-42440-0412 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing Test Summary PK-42440-001 PS-5556-002 SDA-42440-**** TS-5556-002 This document was generated on 05/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-28-6041

1. 物料型号： - 型号：0015286041 - 系列：42440 - 产品名称：Mini-Fit BMITM

2. 器件简介： - 描述：Peg PCB Lock, 4 Circuits, PA Polyamide Nylon 6/6, UL 94V-2, Select Gold (Au) Plating, without Drain Holes - 翻译：Peg PCB锁，4路，PA聚酰胺尼龙6/6，UL 94V-2，选择金（Au）镀层，无排水孔

3. 引脚分配： - 电路（已加载）：4 - 最大电路数：4

4. 参数特性： - 颜色 - 树脂：自然色 - 耐久性（插拔周期最大）：30 - 阻燃性：94V-2 - 导线兼容性：是 - 锁到配合部件：是 - 金属材质：黄铜 - 镀层材质 - 配合：金 - 镀层材质 - 终止：锡 - 树脂材质：尼龙 - 行数：2 - 方向：垂直 - PCB尾长（英寸）：0.140英寸 - PCB尾长（毫米）：3.56毫米 - PCB定位器：是 - PCB保持：是 - 推荐PCB厚度（英寸）：0.070英寸 - 推荐PCB厚度（毫米）：1.80毫米 - 包装类型：托盘 - 配合接口间距（英寸）：0.165英寸 - 配合接口间距（毫米）：4.20毫米 - 镀层最小：配合（微英寸）：30 - 镀层最小：配合（微米）：0.76 - 镀层最小：终止（微英寸）：100 - 镀层最小：终止（微米）：2.50

5. 功能详解： - 极性化到配合部件：是 - 极性化到PCB：是 - 部分屏蔽：是 - 可堆叠：否 - 表面安装兼容（SMC）：否 - 工作温度范围：-40°C至+105°C - 终止接口：通孔 - 最大每接触电流：13A - 最大电压：600V - 焊接过程数据：最大过程温度持续时间5秒，无铅流程能力（仅限TH），最大过程温度下的最大周期数1，最大过程温度240°C

6. 应用信息： - 产品家族：PCB头 - 系列：42440 - 应用：板对板、线对板 - 注释：当与45750 Mini-Fit Plus HCS TM压接端子配合使用时，每个电路最大电流为13A。有关电流降额的额外信息，请参见Molex产品规格PS-45750-001。高温。

7. 封装信息： - 包装规格：PK-42440-001 - 产品规格：PS-5556-002 - 销售图纸：SDA-42440- - 测试总结：TS-5556-002
