15-38-9232

厂商：
MOLEX1
封装：
描述：
15-38-9232 - 2.54mm (.100") Pitch SLâ„¢ FFC/FPC Connector - Single Row Male Version D, 23 Circuits -...

数据手册：

下载15-38-9232.pdf

立即购买

详情介绍
数据手册
价格&库存

15-38-9232 数据手册

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015389232 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ FFC/FPC Connector - Single Row Male Version D, 23 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70430 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Comments Overview Product Name FFC/FPC Connectors 70431 Male cgrid__sl_products SL™ Physical Circuits (Loaded) Color - Resin Contact Position Durability (mating cycles max) Entry Angle Flammability Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PCB Locator PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire/Cable Type 23 Black N/A 25 Vertical 94V-0 Phosphor Bronze Tin Tin Polyester Alloy 1 Vertical No None Tube 0.100 In 2.54 mm 150 3.75 150 3.75 No Yes N/A -40°C to +105°C IDT or Pierce FFC/FPC Search Parts in this Series 70431Series Electrical Current - Maximum per Contact Voltage - Maximum 2A 250V Material Info Reference - Drawing Numbers Product Specification Sales Drawing PS-70430 SDA-70431-**** This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-38-9232

1. 物料型号： - 型号：0015389232

2. 器件简介： - 产品系列：FFC/FPC连接器 - 产品名称：SLTM - 概述：2.54mm（.100"）Pitch SLTM FFC/FPC连接器 - 公头

3. 引脚分配： - 电路（已加载）：23 - 引脚排列：垂直

4. 参数特性： - 耐用性（最大插拔次数）：25次 - 进入角度：垂直 - 阻燃性：94V-0 - 金属材质：磷青铜 - 接触镀层：锡 - 终止镀层：锡 - 树脂材料：聚酯合金 - 行数：1 - 方向：垂直 - PCB定位：芯片无 - PCB保持：无 - 包装类型：管装 - 接口间距（英寸）：0.100 In - 接口间距（毫米）：2.54 mm - 镀层最小：配合（微英寸）：150 - 镀层最小：配合（微米）：3.75 - 镀层最小：终止（微英寸）：150 - 镀层最小：终止（微米）：3.75 - 极化到PCB：否 - 可堆叠：是 - 表面贴装兼容（SMC）：不适用

5. 功能详解： - 电气特性： - 每个接触最大电流：2A - 最大电压：250V

6. 应用信息： - 工作温度范围：-40°C至+105°C - 终止接口样式：IDT或刺穿

7. 封装信息： - 封装类型：FFC/FPC
