5239-12

This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0009524124 Active kk 3.96mm (.156") Pitch KK® Crimp Housing, Female, Friction Ramp, 12 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-5239-002 (PDF) Product Specification PS-5239-003 (PDF) Product Specification PS-5239-004 (PDF) Product Specification PS-5239-005 (PDF) Product Specification PS-5239-006 (PDF) Product Specification PS-5239-007 (PDF) Product Specification PS-5239-010 (PDF) Product Specification PS-5239-011 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification TUV R72090224 General Product Family Series Overview Product Name Crimp Housings 5239 kk KK® Physical Circuits (maximum) Color - Resin Flammability Gender Glow-Wire Compliant Lock to Mating Part Material - Resin Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to Mating Part Stackable Temperature Range - Operating 12 Natural 94V-2 Female No Yes Nylon 1 Bag No 0.156 In 3.96 mm Yes No -40°C to +105°C Search Parts in this Series 5239Series Mates With Right Angle PCB Header, 5274 5272 , Vertical PCB Header 5271 , 5273 Use With 5168 Cat Ear Crimp Terminals for 22-28 AWG, 5167 Cat Ear Crimp Terminals for 18-24 AWG, 2478 Crimp Terminal, 2578 Crimp Terminal Material Info Old Part Number 5239-12 Reference - Drawing Numbers Product Specification PS-5239-002, PS-5239-003, PS-5239-004, PS-5239-005, PS-5239-006, PS-5239-007, PS-5239-010, PS-5239-011, RPS-5239-001 SD-5239-N Sales Drawing This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
