0039000059

This document was generated on 11/02/2018 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: 0039000059 Active Overview: Description: Mini-Fit Jr. Power Connectors Mini-Fit Female Crimp Terminal, Tin (Sn) over Phosphor Bronze, 18-24 AWG, Reel Documents: Drawing (PDF) Product Specification PS-51010-003 (PDF) Product Specification PS-51010-004 (PDF) Product Specification PS-51045-003 (PDF) Product Specification PS-52252-001 (PDF) Product Specification PS-54849-004-001 (PDF) Product Specification PS-5556-001-001 (PDF) Product Specification PS-5556-002-001 (PDF) Product Specification TS-5556-002-001 (PDF) Packaging Specification PK-5556-001-001 (PDF) Test Summary 55560000-TS-000 (PDF) RoHS Certificate of Compliance (PDF) EU ELV Compliant General Product Family Series Application Crimp Quality Equipment Overview Packaging Alternative Product Name UPC Crimp Terminals 5556 Power, Wire-to-Board, Wire-to-Wire Yes Mini-Fit Jr. Power Connectors 39-00-0060 (Loose) Mini-Fit 800753584662 Physical Durability (mating cycles max) Gender Material - Metal Material - Plating Mating Material - Plating Termination Net Weight Packaging Type Plating min - Mating Plating min - Termination Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² 30 Female Phosphor Bronze Tin Tin 0.127/g Reel 0.889µm 0.914µm Crimp or Compression 1.30-3.10mm 18, 20, 22, 24 N/A Electrical Current - Maximum per Contact Voltage - Maximum 9.0A 600V Solder Process Data Lead-freeProcess Capability N/A Material Info Engineering Number 5556PBT Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing Test Summary Series image - Reference only PK-5556-001-001 PS-51010-003, PS-51010-004, PS-51045-003, PS-52252-001, PS-54849-004-001, PS-5556-001-001, PS-5556-002-001, TS-5556-002-001 55560000-SD-000 55560000-TS-000 EU RoHS China RoHS Compliant REACH SVHC Not Contained Per ED/61/2018 (27 June 2018) Halogen-Free Status Low-Halogen For more information, please visit Contact US China ROHS ELV RoHS Phthalates Green Image Compliant Not Contained Search Parts in this Series 5556 Series Mates With 5558 Mini-Fit Crimp Male Terminals. Mini-Fit Jr. Header, Dual Row, 5566 , 5569 Use With 5557 Mini-Fit Jr. Receptacle Housing, 30067 Mini-Fit TPA, 42474 Mini-Fit BMI Panel Mount This document was generated on 11/02/2018 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Molex: 39-00-0059 39-00-0059 (Mouser Reel) 39-00-0059 (Cut Strip)
