0500348000

10 9 8 7 5 6 4 3 2 1 F F E E D D C C B B ORDER No. CONNECTOR SERIES No. 50034-8*00 オーダー番号 THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION MATERIAL 錫メッキ済、リン青銅 PHOS. BRO. TIN-PLATED 適用電線範囲 WIRE RANGE AWG #26～#30 適用被覆外径 INS. RANGE ⌀1.4 MAX. 6 材料 A DOCUMENT STATUS FORMAT: Met-lega-master-tb-prod-A3 REVISION: D DATE: 2018/01/18 10 P1 RELEASE DATE 9 2020/02/28 02:39:08 8 7 DIMENSION UNITS SCALE mm 10:1 CURRENT REV DESC: OBSOLETED PART NUMBER GENERAL TOLERANCES (UNLESS SPECIFIED) GENERAL TOLERANCES (UNLESS SPECIFIED) UNDER 10 OVER 10 OVER UNDER 30 30 ANGULAR 5 MM INCH 4 PLACES ± ± 3 PLACES ± ± ±0.2 2 PLACES ± ± ± ± ±0.25 0 PLACES ± ± ±0.3 ±3° 1 PLACE ANGULAR TOL ± DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 4 ° EC NO: 632260 DRWN: AKUMAR19 CHK'D: GGA APPR: GGA INITIAL REVISION: DRWN: KKOHAMA APPR: MFUKUSHIMA THIRD ANGLE PROJECTION 2020/01/30 2020/02/28 2020/02/28 PRODUCT CUSTOMER DRAWING 2000/03/28 2000/03/30 SERIES A3-SIZE 50034 1 E DOC TYPE DOC PART REVISION DOCUMENT NUMBER DRAWING 3 2.0 BOARD IN CONN. CRIMP PIN SD-50034-002 MATERIAL NUMBER PSD 001 CUSTOMER GENERAL MARKET SEE TABLE 2 SHEET NUMBER 1 OF 1 1 A
