105133-0001

9 7 8 5 6 3 1 0.80 (2X) 2.15 5.60 DATE CODE 0.65 0.45 (5X) PITCH PIN 1 0.50 (3X) A (3X) 4.05 0.30 REF F 1.50 (5X) 1.20 E 2 COVER 2.80 (2X) F 4 1.00 10 0.70 (2X) PIN 5 E ⌀ 3.00 REF PICK AND PLACE AREA R 0.25 TYP 2.80 RECOMMENDED PCB LAYOUT (THICKNESS: 1.6mm) GENERAL TOLERANCE: ±0.05 3.1 4.45 **** 6.7 1.10 D 5 4 3 2 1 8.0 6.2 0.65 PITCH C 0.8 (5X) 3.0 2.79 ±0.10 2.15 C 0.25 (5X) DIMPLE 2.9 1.85 +0.08 -0.02 PIN 5 2.60 0.48 +0.05 -0.00 0.65 PITCH 0.22 MIN 6.90 +0.06 -0.02 PIN 1 D D+ DVBUS PIN NAME PIN ASSIGNMENT 4.75 ±0.05 8.0 2.60 GND ID 0.37 MIN 3.5 MAX 105133-0002 1.70 105133-0001 2.30 PART NUMBER DIM A NOTES: 1. MATERIAL: HOUSING & COVER: HIGH TEMPERATURE THERMOPLASTIC, BLACK, UL94V-0; TERMINAL: COPPER ALLOY, THICKNESS: 0.15mm; SHELL: STAINLESS STEEL, THICKNESS: 0.30mm. 2. PLATING: TERMINAL: CONTACT AREA: MINIMUM 0.75 MICRON GOLD; SOLDER TAIL AREA: GOLD FLASH; UNDER PLATING: NICKEL 2.0 MICRON MINIMUM. SHELL: 1.27 MICRON MINIMUM SOLDERABLE NICKEL PLATING OVER ALL. 3. TAIL COPLANARITY 0.08mm MAXIMUM. 4. PRODUCT SPECIFICATION: PS-105133-001. 5. PACKAGE SPECIFICATION: PK-105133-001. B A DOCUMENT STATUS FORMAT: master-tb-prod-A3 REVISION: J1 DATE: 2021/05/01 P1 RELEASE DATE 9 2022/06/08 B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION SCALE mm NTS ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 3.0 ° 0.15 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 7 CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) 02:43:32 8 DIMENSION UNITS 6 5 4 SALES DRAWING FOR USB, MICRO-B VERTICAL TYPE EC NO: 678130 DRWN: XQZHANG CHK'D: AYIN APPR: AYIN INITIAL REVISION: DRWN: XJSONG APPR: RZHANG THIRD ANGLE PROJECTION 2021/10/28 2022/06/08 2022/06/08 PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2010/08/02 2010/11/11 DRAWING SERIES A3-SIZE 105133 3 SD-105133-001 MATERIAL NUMBER PSD 000 CUSTOMER GENERAL MARKET SEE TABLE 2 G SHEET NUMBER 1 OF 1 1 A
