10 F 9 7 8 JUMPER P/N LENGTH L m [in] MTP CONN. TYPE 106267-2001 0.5 +0.1/-0 [19.69 +4.0/-0] FEMALE 106267-2011 0.5 +0.1/-0 [19.69 +4.0/-0] 5 6 4 3 2 1 CONNECTIONS P1-1 THRU P1-12 P2-1 THRU P2-12 F MALE 106267-2013 0.2 +0.05/-0 [8.0 +2.0/-0] E E B MTP CONNECTOR LABEL 3 A VERSABEAM POD CONNECTOR 12 FIBER BARE RIBBON, MM 50/125µm (NON-PEELABLE) C P2 P1 D 1.3 1.0 1.0 32 25 25 C D LENGTH L (SEE TABLE) MTP CONNECTOR KEY WHITE STRIPE FIBER 1 C VIEW B C 12 1 12 1 5.8 SECTION C-C (TYP.) SCALE 5:1 VIEW A SCALE 5:1 NOTES: B B 1. DUST CAPS ARE NOT SHOWN BUT INCLUDED. MTP MALE CONNECTOR IS SHOWN. FEMALE CONNECTOR DOES NOT CONTAIN PINS. THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION 2. INSERTION LOSS @ 850nm TO AN INTERPOSER: 2.0 dB. THROUGHPUT LOSS (MTP+VERSABEAM POD): 1.2dB. TEST DATA IS SENT WITH JUMPER. DIMENSION UNITS SCALE INCH/MM 1:1 GENERAL TOLERANCES (UNLESS SPECIFIED) MM 3. LABEL IS PRINTED WITH MOLEX NAME, PART NUMBER AND SERIAL NUMBER. A ± 3 PLACES ± ± 2 PLACES ± ± ± ± 0 PLACES ± ± ANGULAR TOL FORMAT: Eng-lega-master-tb-prod-B REVISION: E DATE: 2020/01/14 P1 RELEASE DATE 9 2021/06/01 ± 0.5 ° DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 13:36:35 8 7 6 5 4 MTP12 TO VERSABEAM POD JUMPER, MM 50/125UM INCH 4 PLACES ± 1 PLACE DOCUMENT STATUS CURRENT REV DESC: OBSOLETED PART NUMBERS AS PER PCN#506884 EC NO: 662763 DRWN: SKANDB CHK'D: GGA APPR: GGA INITIAL REVISION: DRWN: EEFUNG APPR: THIRD ANGLE PROJECTION 2021/01/27 2021/06/01 2021/06/01 2010/08/09 2010/08/27 DRAWING SERIES B-SIZE 106267 3 PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER SD-106267-2001 MATERIAL NUMBER SEE TABLE 2 PSD 001 CUSTOMER GENERAL MARKET F SHEET NUMBER 1 OF 1 1 A
