12 11 SAP NUMBER H 10 ENGINEERING NUMBER 9 7 8 5 6 4 3 2 1 FINISHED LENGTH 1300540012 ERWAAJ4002M002 7.87" +.75-0[.2M +19.0-0] 1300540013 ERWAAJ4002M020 76.56"+3.50"-0[2M+89.0-0] H 1.63REF 41.4 FACE VIEW G G .53REF 13.5 .77REF 19.6 8 1 2 (RD+) 1 (TD+) 3 4 3 (TD-) F B F 4 (RD-) 7 2 .75 REF 19.0 M16X1.5 6 1.97REF 50.0 1.60REF 40.6 LABEL 5 FINISHED LENGTH E E WIRING CONNECTION TYPICAL KNOCKOUT 1 ORANGE 2 BLUE 3 ORANGE-WHITE 4 BLUE-WHITE D D .54 REF 13.7 C B C NOTES: 1.MATERIALS: SEE TABLE 2. FINISH: SEE TABLE 3. ELECTRICAL SPECIFICATIONS: VOLTAGE: 125V CURRENT RATING: 1.5A 4. ENVIRONMENTAL: TEMP RANGE: -25°C - 75°C 5. ASSEMBLY IS ROHS COMPLIANT BY EXCEPTION ITEM 8 7 6 5 A 4 3 2 1 COMPONENT LABEL SLEEVE PANEL NUT O-RING SOCKET CONTACT INSERT 4P RECEPT. SHELL CABLE DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 MATERIAL MYLAR BRASS Cu ALLOY BUNA-N Cu ALLOY NYLON BRASS ETHERNET CAT 5e(PVC) P1 RELEASE DATE 11 B FUNCTIONAL THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION SCALE SYMBOLS DIMENSION UNITS CURRENT REV DESC: UPDATE PIN 4 TO RD- = FINISH = 0 0 BLK/YLW NICKEL PLATED BLACK GOLD PLATED BLACK NICKEL PLATED JACKET:TEAL 2021/05/14 10 1:1 GENERAL TOLERANCES (UNLESS SPECIFIED) ANGULAR TOL ± 4 PLACES ± DIVISIONAL 3 PLACES SYMBOLS ± 2 PLACES ± = NICKEL PLATED mm 0 1 PLACE ± 0 PLACES ± 0.5 ° DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 23:22:57 9 8 7 6 5 EC NO: 663650 DRWN: CCHRASTKA CHK'D: MZIELINSKI APPR: BWOODMAN INITIAL REVISION: DRWN: BRUPERT APPR: JFMURPHY THIRD ANGLE PROJECTION 2021/05/11 2021/05/13 2021/05/14 M12 D-CODE CORDSET RECEPTACLE PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2010/01/29 2010/01/29 DRAWING SERIES SD-130054-001 MATERIAL NUMBER CUSTOMER C-SIZE 130054 4 3 PSD 001 GENERAL MARKET 2 B SHEET NUMBER 1 OF 1 1 A
