172709-0002

5 6 4 3 2 1 TPA CIRCUIT SIZE PART NUMBER PARTS PER BAG/CARTON (DU) POLYBAGS PER CARTON 1 2 3 4 5 6 7 8 9 10 11 12 1727090*01 1727090*02 1727090*03 1727090*04 1727090*05 1727090*06 1727090*07 1727090*08 1727090*09 1727090*10 1727090*11 1727090*12 5600 4400 3200 2400 2000 1600 1600 1500 1300 1200 1100 1000 1 1 1 1 1 1 1 1 1 1 1 1 D 967130003 POLYBAG, 300 X 500 FLAT QTY: (1) D PACKAGING PROCEDURE: C C 1. PREPARE CARTON BY FOLDING AND TAPING BOTTOM FLAPS OF CARTON WITH 2 INCH WIDE TRANSPARENT PACKAGING TAPE. TAPE SHOULD EXTEND UP SIDES OF CARTON AT LEAST 76 MM (3 INCHES). 2. ADD PARTS TO ZIP LOCK POLYBAG PER PRESCRIBED QUANTITY IN CHART THEN SEAL ZIP LOCK. 3. PLACE FILLED POLYBAG INTO CARTON WITH SIDE FACING BOTTOM OF CARTON. TOP OF POLYBAG MAY BE FOLDED OVER FOR EASE OF PLACEMENT INTO CARTON. 4. EXCESS SPACE IN THE CARTON IF PRESENT SHOULD BE FILLED WITH FOAM SHEET OR BUBBLE WRAP. 5. CLOSE TOP FLAPS OF CARTON AND TAPE. EXTEND TAPE DOWN SIDES OF CARTON AT LEAST 76 MM (3 INCHES). 6. ADD LABELS TO CARTONS AS REQUIRED. B B 967070017 OR 885960361 (EQUIVALENT) 364 X 176 X 84 CARTON QTY: (1) SYMBOLS MM/INCH 1:10 = 0 GENERAL TOLERANCES (UNLESS SPECIFIED) 6 P1 RELEASE DATE 2018/07/27 5 11:32:00 C 4 ± 4 PLACES ± = 0 3 PLACES ± = 0 2 PLACES ± 1 PLACE ± 0 PLACES ± = 0 DOCUMENT STATUS ANGULAR TOL = 0 = 0 FORMAT: master-tb-prod-A REVISION: H DATE: 2018/01/18 SCALE = 0 = 0 A THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS = 0 ° DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS CURRENT REV DESC: NOTE 8 REMOVED EC NO: 178954 DRWN: SGANGADHARDO CHK'D: SGANGADHARDO APPR: ISHWARG INITIAL REVISION: DRWN: TGREGORI APPR: RHODGE THIRD ANGLE PROJECTION DRAWING PACKAGING SPECIFICATION MINI-FIT TPA2 TPA SERIES 172709 2018/07/26 2018/07/27 2018/07/27 A PACKAGING DESIGN DRAWING PK-172709-0000 MATERIAL NUMBER SERIES A-SIZE 172709 3 DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2015/06/16 2015/06/16 2 SEE TABLE PDD 000 D3 SHEET NUMBER CUSTOMER GENERAL MARKET 1 1 OF 1
