This document was generated on 09/10/2018 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0022035065 Active Mini-SPOX Wire-to-Board Connector System 2.50mm Pitch Mini-SPOX Wire-to-Board Header, Vertical, Shrouded, 6 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-5264-001-001 (PDF) Packaging Specification SPK-5267-001-001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only Agency Certification CSA UL LR19980 E29179 General Product Family Series Application Overview Product Name UPC PCB Headers 5267 Signal, Wire-to-Board Mini-SPOX Wire-to-Board Connector System Mini-SPOX 800753591523 Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Capable Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Plating Mating Material - Plating Termination Material - Resin Net Weight Number of Rows Orientation PC Tail Length PCB Locator PCB Retention PCB Thickness - Recommended Packaging Type Pitch - Mating Interface Plating min - Mating Plating min - Termination Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 6 6 Natural 30 No 94V-0 No No None Yes Tin Tin Nylon 532.600/mg 1 Vertical 3.50mm No Yes 1.60mm Bag 2.50mm 4.064µm 4.064µm Yes No Fully No No -40° to +105°C Through Hole EU ELV Not Relevant EU RoHS China RoHS Compliant REACH SVHC Not Contained Per ED/61/2018 (27 June 2018) Halogen-Free Status Not Low-Halogen Need more information on product environmental compliance? Email productcompliance@molex.com Please visit the Contact Us section for any non-product compliance questions. China ROHS ELV Prop65 RoHS Phthalates Green Image Not Relevant Compliant Not Contained Search Parts in this Series 5267 Series Mates With 5264 Mini-SPOX Wire-to-Board Crimp Housing, 42219 SPOX IDT Receptacle Housing Electrical Current - Maximum per Contact Voltage - Maximum 3.0A 250V Material Info Engineering Number 5267-06A Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing SPK-5267-001-001 PS-5264-001-001 SD-5267-NA This document was generated on 09/10/2018 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
