This document was generated on 09/20/2021 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0026481095 Active KK Interconnect Solutions KK 396 Breakaway Header, Vertical, Square Pin, with Friction Lock, 9 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) 3D Model (PDF) Product Specification PS-08-50-001 (PDF) Packaging Specification PK-41671-001-001 (PDF) Symbol Footprint Data SYM-41671-0008-001 (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR19980 E29179 Application tooling part link Application Tooling Part Link 11-20-0901 General Product Family Series Application Overview Product Name UPC PCB Headers 41671 Power, Wire-to-Board KK Interconnect Solutions KK 396 800753586567 Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Capable Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Net Weight Number of Rows Orientation PC Tail Length PCB Locator PCB Retention PCB Thickness - Recommended Packaging Type Pitch - Mating Interface Pitch - Termination Interface Plating min - Mating Plating min - Termination Polarized to Mating Part Polarized to PCB Shrouded Stackable Temperature Range - Operating Yes 9 9 Black 25 94V-0 No Yes Brass Tin Tin Polyester 3.327/g 1 Vertical 4.37mm No None 1.60mm Bag 3.96mm 3.96mm 5.080µm 5.080µm Yes No Partial No See Product Specification Series image - Reference only EU ELV Not Relevant EU RoHS China RoHS Compliant REACH SVHC Not Contained Per D(2021)4569-DC (8 July 2021) Halogen-Free Status Not Low-Halogen For more information, please visit Contact US China ROHS ELV RoHS Phthalates Green Image Not Relevant Not Contained Search Parts in this Series 41671 Series Mates With 2139 KK Crimp Housing, 41695 KK Crimp Housing, 6442 KK Crimp Housing, 2145 PCB Connector, 41815 PCB Connector, 3069 KK Crimp Housing Termination Interface: Style Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7.0A 250V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-freeProcess Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 005 WAVE 001 235 Material Info Engineering Number A-41671-C09A197 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing Symbol/Footprint Data PK-41671-001-001 PS-08-50-001 SD-41671-001-001, SD-41671-001-002 SYM-41671-0008-001 This document was generated on 09/20/2021 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Molex: 26-48-1095
