507528200

9 7 8 6 5 4 3 2 1 �12� E E D ±0.3 C ±0.4 A ±0.4 B ±0.3 D D SECTION A-A 8 SECTION B-B ±0.25 3.2 0.8 NOTES 1.3 材料及び仕上げ(めっき仕様)：TABLE 1 参照 　 MATERIAL AND FINISHES : SEE TABLE 1 2. 適合ハウジング：51163シリーズ 　 APPLY MATE HOUSING：51163 SERIES 3. 適合リテーナー：51164シリーズ 　 APPLY MATE RETAINER：51164 SERIES 4. 圧着仕様書：507520000-CS PS 000 　 CRIMP SPECIFICATION:507520000-CS PS 000 1 1.8 B A B A 2.45 C C B B 1 部品 PART TABLE 1 2.4 2.48 1.3 1.42 Φ1.28-1.42mm AWG#24-26 リール REEL 507528400 連鎖状 CHAIN 2.9 2.51 1.9 2.05 Φ1.5-1.8mm AWG#20-22 リール REEL 507528200 連鎖状 CHAIN D B C ターミナル 錫めっき：0.9 MICRO METER MINIMUM TERMINAL MATTE TIN リフロー処理(前めっき) REFLOW TREATMENT (PRE-PLATING) DOCUMENT STATUS 9 P1 RELEASE DATE DIMENSION UNITS SCALE mm NTS CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) りん青銅 PHOSPHOR BRONZE FORMAT: master-tb-prod-A3 REVISION: H DATE: 2018/01/18 発注番号 端子形状 絶縁被覆外径範囲 適用電線範囲 梱包形態 INS. RANGE WIRE RANGE PACKAGING ORDER No. FORM THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION 材質 MATERIAL A A 2018/10/23 8 ANGULAR TOL ± 3.0 ° 4 PLACES ± 0.2 3 PLACES ± 0.2 2 PLACES ± 0.2 1 PLACE ± 0.2 0 PLACES ± 0.2 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 07:17:55 7 6 5 4 EC NO: 606178 DRWN: RWATANABE01 CHK'D: KOMURAKAMI APPR: TKANEKO INITIAL REVISION: DRWN: RWATANABE01 APPR: TKANEKO THIRD ANGLE PROJECTION 3 2018/09/25 2018/10/22 2018/10/23 PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2018/03/14 2018/09/10 507520000-SD MATERIAL NUMBER DRAWING SERIES A3-SIZE 50752 2 A MINI-LOCK 2.5 W/B TERMINAL SEE CHART PSD 001 B SHEET NUMBER CUSTOMER GENERAL 1 OF 1 1
