5601250900

9 7 8 5 6 4 3 2 1 GENERAL TOLERANCE USED ON 10 MAX 30 MAX 50 MAX 70 MAX 100 MAX 120 MAX 250 MAX 250 OVER ANGLE ECCENT ±0.15 ±0.20 ±0.30 ±0.40 ±0.50 ±0.75 ±0.90 ±1.4 ±0.5˚ 0.1 E E ISO VIEW D D 3.8 2.05 1.45 6.2 2.65 1.55 20.35 C C CAV. NO. 6.45 NOTES : 1. MATERIAL : POLYESTER (PBT), GLASSFILLED, UL94V-0 COLOR : GRAY 2. APPLICABLE HOUSING : 560123-090* 3. GENERAL TOLERANCE : SEE TABLE 4. EVL AND RoHS COMPLIANT 5. PRODUCT SPECIFICATION : PS-560123-001 6. PACKING SPECIFICATION : PK-560125-001 B B 1.75 ORDER NO. MATERIAL NO. COLOR 560125-0900 5601250900 GRAY = 0 = 0 = = C RELEASE STATUS FORMAT: master-tb-prod-A3 REVISION: G DATE: 2015/12/14 9 RELEASE DATE 8 7 6 0 0 = 0 = 0 5 TOLERANCES (UNLESS SPECIFIED) MM DRWN BY 5:1 DATE ANGULAR TOL ± 0.0 ° ± 4 PLACES 0.0 A 3 PLACES ± 0.0 2 PLACES ± 0.0 ± ± 0 PLACES 2016/12/22 A DATE PRODUCT CUSTOMER DRAWING 0.0 0.0 JHJANG DRAWING SIZE DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 4 NEW 2.0 PITCH W/B CONN. REC. 9WAY ISL DURACLIK ISL SERIES DATE BCYOON APPR BY 1 PLACE 2016/10/11 SJLEE06 CHK'D BY REV 0 NEW RELEASE = 111723 SJLEE06 BCYOON JHJANG A 0 EC NO: DRWN: CHK'D: APPR: = 2016/12/22 2016/12/23 2016/12/28 QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS SCALE SYMBOLS GENERAL 2016/12/28 THIRD ANGLE PROJECTION A3 SERIES MATERIAL NUMBER 560125 5601250900 DOCUMENT NUMBER DOC TYPE DOC PART SHEET NUMBER 5601250900 3 CUSTOMER 2 PSD 1 OF 1 000 1
