74754-0101

12 11 10 9 7 8 15.12 (OUTSIDE TABS) 6 5 4 3 2 1 747540101 SHOWN H H 14.93 G G OPTIONAL POLYIMIDE INSULATOR ATTACHED TO BOTTOM OF CAGE MATERIAL NUMBER 747540163 REFERENCE F F EMI SPRING FINGER E PART NO. POLYIMIDE INSULATOR 747540101 747540108 ----- SFP+ 1X1 CAGE WELD POINT PACKAGING QUANTITY PLATING SHEET NICKEL NICKEL 1 2 TRAY TRAY 0 6 E 15.90 REF ( OVER SPRING FINGERS) 14.00 ±0.10 (INSIDE CAGE) D 8.95 ±0.10 (INSIDE CAGE) 10.85 REF ( OVER SPRING FINGERS) D 49.0 74754XXXX WKYR 3.05 C C 11.50 REF COMPLETED / PARTIAL PART NO. AND WEEK/YEAR DATE CODE TO BE PRINTED / STAMPED ON THE SIDE OF COMPLETED CAGE ASSEMBLY APPROXIMATELY AS SHOWN. WEEK/YEAR DATE CODE TABLE WK 01 THRU 52 OR 53 EXAMPLE: 01 = FIRST WEEK OF YEAR 52 = LAST WEEK OF YEAR YR 22, 23, 24 ETC. EXAMPLE: YEAR 2022 = 22 B NOTES: B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION A 1. MATERIAL: CAGE: COPPER ALLOY, THICKNESS 0.25mm, PLATING REFER TO TABLE. SPRING FINGER: NICKEL PLATED COPPER ALLOY, THICKNESS 0.10mm 2. PRESS FIT LEGS 3.05 LONG 1.57 MINIMUM PCB THICKNESS FOR SINGLE SIDED USE 3. OPTIONAL LIGHT PIPE ASSEMBLY AVAILABLE 4. PORTS ARE DESIGNED FOR SFP+ TRANSCEIVERS AND ARE BACKWARDS COMPATIBLE WITH SFP TRANCEIVERS 5. NO RoHS EXEMPTIONS DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 P1 RELEASE DATE 11 2022/06/06 10 DIMENSION UNITS SCALE mm 3:1 GENERAL TOLERANCES (UNLESS SPECIFIED) ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 0.5 ° 0.13 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 01:53:47 9 CURRENT REV DESC: 8 7 6 5 EC NO: 708952 DRWN: TKUMARKC CHK'D: SMALLESHAPPA APPR: SCHIEN INITIAL REVISION: DRWN: MAZAM APPR: RCHEN08 THIRD ANGLE PROJECTION 4 2022/05/31 2022/06/01 2022/06/06 SFP+ 1X1 CAGE ASSY PRESS FIT, WITH EMI SPRING FINGERS PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2017/01/16 2018/01/05 DRAWING SERIES C-SIZE 74754 3 747540101 MATERIAL NUMBER PSD ASY CUSTOMER SEE P/N TABLE 2 M3 SHEET NUMBER GENERAL MARKET 1 OF 5 1 A 12 11 10 9 8 7 6 5 4 3 2 1 747540108 H H G G 747540108 WKYR F COMPLETED PART NO. AND WEEK/YEAR DATE CODE TO BE PRINTED ON THE SIDE OF COMPLETED CAGE ASSEMBLY APPROXIMATELY AS SHOWN. F MOLEX INTERNAL USE ONLY E E D D C C B B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS SCALE mm 5:1 CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) A DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 P1 RELEASE DATE 11 2022/06/06 10 ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 0.5 ° 0.13 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 01:53:47 9 8 7 6 5 EC NO: 708952 DRWN: TKUMARKC CHK'D: SMALLESHAPPA APPR: SCHIEN INITIAL REVISION: DRWN: MAZAM APPR: RCHEN08 THIRD ANGLE PROJECTION 4 2022/05/31 2022/06/01 2022/06/06 SFP+ 1X1 CAGE ASSY PRESS FIT, WITH EMI SPRING FINGERS PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2017/01/16 2018/01/05 DRAWING SERIES C-SIZE 74754 3 747540101 MATERIAL NUMBER PSD ASY CUSTOMER SEE P/N TABLE 2 M3 SHEET NUMBER GENERAL MARKET 2 OF 5 1 A 12 11 10 9 8 7 6 5 4 3 2 1 PCB LAYOUT FOR SINGLE SIDE MOUNT H H 1.00 14.25 B TOP LEFT HOLE OF ADJACENT CAGE AT MINIMUM SPACING 11.08 HATCHED AREA DENOTES COMPONENTS AND TRACE KEEP-OUT (EXCEPT CHASSIS GROUND) 8.58 2.00 5.68 A 0.00 G G 4.50 TYP 10X ⌀ 1.05 ±0.05 (SHOWN AS ⌖ ) ⌖ 0.1 A B 9.50 TYP 14.50 F F 15.50 TYP 19.50 9X ⌀ 0.95 ±0.05 (SHOWN AS ⌖ ) ⌖ 0.1 A B 24.50 TYP 27.30 TYP 29.50 32.00 TYP E E 34.50 THIS AREA DENOTES COMPONENT KEEP-OUT (TRACES ALLOWED) 35.40 TYP 37.00 TYP 1.00 TYP 39.50 41.60 TYP SEE DETAIL1 2X 2.00 42.30 D 2.33 D ⌀ 0.85 ±0.05 2.33 ⌖ 0.1 A B 7.13 2.00 2.33 5.13 11.93 12.25 DETAIL 1 SCALE 8:1 HOST CONNECTOR DETAIL C C B B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS SCALE mm 3:1 CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) A NOTES: 1. PADS AND VIAS CONNECT TO CHASSIS GROUND (RECOMMEND PADS TO BE 2.00mm SQUARE) 2. RECOMMENDED THRU HOLE PLATING INCLUDES HASL, OSP, OR IMMERSION (GOLD, SILVER, OR TIN). 3. CONNECTOR PAD LAYOUT PER SFP+ MSA WILL ACCOMMODATE MOLEX CONNECTOR SERIES 74441 OR EQUIVALENT. DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 P1 RELEASE DATE 11 2022/06/06 10 ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 0.5 ° 0.13 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 01:53:47 9 8 7 6 5 EC NO: 708952 DRWN: TKUMARKC CHK'D: SMALLESHAPPA APPR: SCHIEN INITIAL REVISION: DRWN: MAZAM APPR: RCHEN08 THIRD ANGLE PROJECTION 4 2022/05/31 2022/06/01 2022/06/06 SFP+ 1X1 CAGE ASSY PRESS FIT, WITH EMI SPRING FINGERS PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2017/01/16 2018/01/05 DRAWING SERIES C-SIZE 74754 3 747540101 MATERIAL NUMBER PSD ASY CUSTOMER SEE P/N TABLE 2 M3 SHEET NUMBER GENERAL MARKET 3 OF 5 1 A 12 11 10 9 7 8 6 5 4 3 2 1 BEZEL AND BOARD POSITION DIMENSIONS FOR SINGLE SIDE MOUNTING (SPRING FINGER) H H 15.45 ±0.10 45.50 REF G G 10.40 ±0.10 F A REF 74754XXXX WKYR B ±0.10 BEZEL OPENING BELOW PCB PAD SURFACE F A 0.80 MIN 3.50 ±0.30 R 0.3 REF TYP E E SFP+ 1X1 CAGE PART NO. DIM A DIM B 747540101 747540108 9.47 9.47 0.43 0.43 D D C C B B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS SCALE mm 3:1 CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) A DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 P1 RELEASE DATE 11 2022/06/06 10 ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 0.5 ° 0.13 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 01:53:47 9 8 7 6 5 EC NO: 708952 DRWN: TKUMARKC CHK'D: SMALLESHAPPA APPR: SCHIEN INITIAL REVISION: DRWN: MAZAM APPR: RCHEN08 THIRD ANGLE PROJECTION 4 2022/05/31 2022/06/01 2022/06/06 SFP+ 1X1 CAGE ASSY PRESS FIT, WITH EMI SPRING FINGERS PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2017/01/16 2018/01/05 DRAWING SERIES C-SIZE 74754 3 747540101 MATERIAL NUMBER PSD ASY CUSTOMER SEE P/N TABLE 2 M3 SHEET NUMBER GENERAL MARKET 4 OF 5 1 A 12 11 10 9 8 7 6 5 4 3 2 1 H H REV DATE E 2014/01/10 F 2014/02/24 G H J 2014/07/04 2014/09/11 2015/02/25 K 2018/01/04 L L1 2018/01/23 2018/02/05 L2 2018/03/07 L3 2018/03/12 SHEET 1: G06: CORRECTED SYSTEM ERROR TO ADD THE 74754XXXX WKYR SHEET 3: F04: CHANGED FROM SPECIFIC P/N 747540101 TO COMMON P/N 74754XXXX FOR BETTER UNDERSTANDING L4 2018/03/20 SHEET 3: F04: CORRECTED THE SYSTEM ERROR ABOUT POSITION OF 74754XXXX WKYR M 2018/06/14 ADDED SHEET 2 FOR 747540108 DETAIL AND ADDED 747540108WKYR PRINTING ON SIDE OF CAGE FOR BETTER UNDERSTANDING M1 2020/02/06 SHEET 1 & SHEET 4: REMOVED OBSOLETE PART NUMBERS 747540132, 747541101 FROM TABLE M2 2021/05/20 M3 2022/05/31 OBSOLETED PART NUMBER 747540133. SHEET 1: REMOVED P/N 747548101 FROM PART NUMBER TABLE. SHEET 4: REMOVED P/N 747548101 FROM TABLE. SHEET 5: DELETED TAPE AND REEL PACKAGING DETAIL. G F E DESCRIPTION 1. ADDED P/N: 747541101. [SHT 1] 2. ADDED P/N: 747540108. [SHT 1] 3. ADDED REV HISTORY LIST. [SHT 5] 1. ADDED P/N: 747540132 & 747540133 [SHT 1] [SHT 3] REMOVE NOTE 6 [SHT 1] 1. REVISED 747540132 & 747540133 DIM B FROM 0.40 TO 0.25.[SHEET 3] 1. ADDED DIMENSION " 11.50 REF. " @D14. [SHEET 1] 1. P/N DESCRIPTION CHANGED AS "COMPLETED / PARTIAL PART NO. AND WEEK/YEAR DATE CODE TO BE PRINTED / STAMPED ON THE SIDE OF COMPLETED CAGE ASSEMBLY APPROXIMATELY AS SHOWN." [SHEET 1] 1. REMASTERED FROM SD-74754-0101 REV_ J TO 747540101 PSD ASY REV_ K IN NX. 2. SHEET 3 : E7 : ADDED DIMENSION R0.3 REF TYP 1.SHEET 1: CORRECTED TYPO TO CHANGE WELDING POINT FROM 14 TO 6 PCS MATCHING WITH ACTUAL SAMPLE FOR 747540108 UPDATED DRAWING TO REMOVE PRE-RELEASE STAMP FOR ALL SHEET BECAUSE OF SYSTEM PROBLEM UPDATED THE DRAWING TO ADD THE MATERIAL NUMBER ON THE TITLE BLOCK G F E D D C C B B THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION DIMENSION UNITS SCALE mm 1:1 CURRENT REV DESC: GENERAL TOLERANCES (UNLESS SPECIFIED) A DOCUMENT STATUS 12 FORMAT: master-tb-prod-C REVISION: J DATE: 2020/01/14 P1 RELEASE DATE 11 2022/06/06 10 ANGULAR TOL ± 4 PLACES ± 3 PLACES ± 2 PLACES ± 1 PLACE ± 0 PLACES ± 0.5 ° 0.13 0.25 DRAFT WHERE APPLICABLE MUST REMAIN WITHIN DIMENSIONS 01:53:47 9 8 7 6 5 EC NO: 708952 DRWN: TKUMARKC CHK'D: SMALLESHAPPA APPR: SCHIEN INITIAL REVISION: DRWN: MAZAM APPR: RCHEN08 THIRD ANGLE PROJECTION 4 2022/05/31 2022/06/01 2022/06/06 SFP+ 1X1 CAGE ASSY PRESS FIT, WITH EMI SPRING FINGERS PRODUCT CUSTOMER DRAWING DOC TYPE DOC PART REVISION DOCUMENT NUMBER 2017/01/16 2018/01/05 DRAWING SERIES C-SIZE 74754 3 747540101 MATERIAL NUMBER PSD ASY CUSTOMER SEE P/N TABLE 2 M3 SHEET NUMBER GENERAL MARKET 5 OF 5 1 A
