90121-0121

This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0901210121 Active cgrid_iii 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Right Angle, 1 Circuit, Tin (Sn) Plating Documents: Drawing (PDF) Product Specification PS-99020-0001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only PCB Headers 90121 Wire-to-Board cgrid_iii C-Grid III™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Overview Product Name Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Yes 1 1 Black 30 No No No None None Brass Tin Tin Polyester 1 Right Angle 0.114 In 2.90 mm No None 0.063 In 1.60 mm Bag 0.000 In 0.00 mm 0.000 In 0.00 mm 120 3 120 3 No No No Yes No -55°C to +125°C Through Hole Search Parts in this Series 90121Series Electrical Current - Maximum per Contact Voltage - Maximum 3A 350V AC/DC Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 Wave Capable (TH only) 1 260 Material Info Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0001 SDA-90121 This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
