15-45-3208

厂商：
MOLEX2
封装：
描述：
15-45-3208 - 2.54mm (.100) Pitch C-GridÂ® PCB Connector, Surface Mount, High Profile, Dual Row, Vert...

数据手册：

下载15-45-3208.pdf

立即购买

详情介绍
数据手册
价格&库存

15-45-3208 数据手册

This document was generated on 05/31/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015453208 Active cgrid__sl_products 2.54mm (.100") Pitch C-Grid® PCB Connector, Surface Mount, High Profile, Dual Row, Vertical, 8 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-71395 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Receptacles 71395 Board-to-Board cgrid__sl_products C-Grid® Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style 8 Black 25 94V-0 No No None No Phosphor Bronze Tin Tin High Temperature Thermoplastic 2 Vertical 0.058 In 1.47 mm Yes None Tray 0.100 In 2.54 mm 150 3.75 150 3.75 No N/A -40°C to +105°C Surface Mount Search Parts in this Series 71395Series Mates With 8624 C-Grid® Breakaway Header, 70246 Straight Header, 70247 Right Angle Header, 70287 C-Grid® Header, 70227 Dual Row C-Grid® Header, 70567 C-Grid® Header, 70280 C-Grid® Breakaway Header, 70524 C-Grid® Breakaway Header, 7 Electrical Current - Maximum per Contact Grounding to PCB Voltage - Maximum 2.5A No 250V Solder Process Data Lead-free Process Capability Process Temperature max. C Reflow Capable (SMT only) 260 Material Info Old Part Number 713950008 Reference - Drawing Numbers Application Specification Packaging Specification Product Specification Sales Drawing AS-71395-001 PK-70873-0304 PS-71395 SDA-71395-1*** This document was generated on 05/31/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-45-3208

1. 物料型号 - 型号：0015453208 - 状态：Active（活跃）

2. 器件简介 - 描述：2.54mm (.100") 间距 C-Grid® PCB连接器，表面贴装，高轮廓，双行。 - 环保合规性：符合欧盟RoHS、中国RoHS、ELV和RoHS标准，REACH SVHC未审核，卤素状态未审核。

3. 引脚分配 - 电路（已加载）：8个 - 行数：2 - 引脚间距：2.54mm（0.100英寸）

4. 参数特性 - 颜色 - 树脂：黑色 - 耐久性（最大插拔次数）：25次 - 阻燃等级：94V-0 - 端子材料：铍青铜 - 镀层 - 接触：锡 - 镀层 - 终止：锡 - 树脂材料：高温热塑性塑料 - PCB定位：有 - 引脚长度（英寸）：0.058 In - 引脚长度（mm）：1.47mm - 包装类型：Tray（托盘）

5. 功能详解 - 应用：板对板连接 - 产品名称：C-Grid® - 电气特性： - 每个接触最大电流：2.5A - 电压最大值：250V - 操作温度范围：-40°C至+105°C

6. 应用信息 - 与8624 C-Grid® Breakaway Header, 70246 Straight Header, 70247 Right Angle Header, 70287 C-Grid® Header, 70227 Dual Row C-Grid® Header, 70567 C-Grid® Header, 70280 C-Grid® Breakaway Header, 70524 C-Grid® Breakaway Header等多种C-Grid®系列头配合使用。

7. 封装信息 - 安装方向：垂直 - 表面贴装兼容（SMC）：不适用（N/A） - 镀层最小厚度 - 接触（微英寸）：150 - 镀层最小厚度 - 接触（微米）：3.75 - 镀层最小厚度 - 终止（微英寸）：150 - 镀层最小厚度 - 终止（微米）：3.75
