15-45-3546

厂商：
MOLEX2
封装：
描述：
15-45-3546 - 2.54mm (.100) Pitch C-GridÂ® PCB Connector, Surface Mount, High Profile, Dual Row, Vert...

数据手册：

下载15-45-3546.pdf

立即购买

详情介绍
数据手册
价格&库存

15-45-3546 数据手册

This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015453546 Active cgrid__sl_products 2.54mm (.100") Pitch C-Grid® PCB Connector, Surface Mount, High Profile, Dual Row, Vertical, 46 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-71395 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Receptacles 71395 Board-to-Board cgrid__sl_products C-Grid® Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style 46 Black 50 94V-0 No No None No Phosphor Bronze Gold Tin High Temperature Thermoplastic 2 Vertical 0.058 In 1.47 mm Yes Yes Tray 0.100 In 2.54 mm 15 0.38 75 1.90 No N/A -40°C to +105°C Surface Mount Search Parts in this Series 71395Series Mates With 8624 C-Grid® Breakaway Header, 70246 Straight Header, 70247 Right Angle Header, 70287 C-Grid® Header, 70227 Dual Row C-Grid® Header, 70567 C-Grid® Header, 70280 C-Grid® Breakaway Header, 70524 C-Grid® Breakaway Header, 7 Electrical Current - Maximum per Contact Grounding to PCB Voltage - Maximum 2.5A No 250V Solder Process Data Lead-free Process Capability Process Temperature max. C Reflow Capable (SMT only) 260 Material Info Old Part Number 71395-0146 Reference - Drawing Numbers Application Specification Packaging Specification Product Specification Sales Drawing AS-71395-001 PK-70873-0662 PS-71395 SDA-71395-0*** This document was generated on 06/07/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-45-3546

1. 物料型号： - 型号：0015453546 - 状态：Active（活跃）

2. 器件简介： - 描述：2.54mm（.100"）间距C-Grid® PCB连接器，表面贴装，高轮廓，双排，垂直，46电路。 - 文档：3D模型图纸（PDF）、产品规格PS-71395（RoHS合规证书）。

3. 引脚分配： - 电路（已加载）：46 - 排数：2 - 引脚间距（接口）：2.54mm（0.100英寸）

4. 参数特性： - 颜色 - 树脂：黑色 - 耐久性（最大插拔次数）：50 - 阻燃性：94V-0 - 表面贴装兼容（SMC）：不适用（N/A） - 操作温度范围：-40°C至+105°C - 电气参数： - 每个接触点最大电流：2.5A - 最大电压：250V

5. 功能详解： - 产品名称：C-Grid® - 物理特性： - PCB定位器：是 - PCB保持：是 - 包装类型：托盘 - 材料： - 金属材质：磷青铜 - 接触镀层：金 - 终止镀层：锡 - 树脂材质：高温热塑性塑料

6. 应用信息： - 应用：板对板（Board-to-Board）

7. 封装信息： - 安装类型：表面贴装 - 引脚长度（PC尾长）：0.058英寸（1.47mm） - 接口风格：表面贴装
