15-47-5030

厂商：
MOLEX2
封装：
描述：
15-47-5030 - 2.54mm (.100) Pitch SLâ„¢ FFC/FPC Connector - Single Row Male Version D, 3 Circuits - M...

数据手册：

下载15-47-5030.pdf

立即购买

详情介绍
数据手册
价格&库存

15-47-5030 数据手册

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015475030 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ FFC/FPC Connector - Single Row Male Version D, 3 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-70430 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Comments Overview Product Name FFC/FPC Connectors 70431 Male cgrid__sl_products SL™ Physical Circuits (Loaded) Color - Resin Contact Position Durability (mating cycles max) Entry Angle Flammability Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PCB Locator PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire/Cable Type 3 Black N/A 50 Vertical 94V-0 Phosphor Bronze Gold Tin Polyester Alloy 1 Vertical No None Tube 0.100 In 2.54 mm 15 0.375 75 1.875 No Yes N/A -40°C to +105°C IDT or Pierce FFC/FPC Search Parts in this Series 70431Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Manual Ribbon 0638170100 Cable Cutter Hand Tool Tool Kit for Standard 0622007400 Manual Press FFC Standard Manual 0622007800 Press for FFC TM-42™ FFC and 0622018700 SL™ Termination Kit TM-42™ FFC and 0622020800 SL™ Press and Termination Kit for 110v applications Electrical Current - Maximum per Contact Voltage - Maximum 2A 250V Material Info Old Part Number 70431-0247 Reference - Drawing Numbers Product Specification Sales Drawing PS-70430 SDA-70431-**** This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-47-5030

1. 物料型号： - 型号：0015475030

2. 器件简介： - 产品名称：SL™ FFC/FPC连接器，单排男性版本D，3电路。 - 概述：2.54mm（.100"）间距SL™ FFC/FPC连接器，单排男性版本。

3. 引脚分配： - 引脚数量：1排。

4. 参数特性： - 电路数（已加载）：物理3 - 颜色-树脂：黑色 - 耐久性（最大插拔次数）：50 - 进入角度：垂直 - 阻燃性：94V-0 - 金属材质：磷青铜 - 镀层-配合：金 - 镀层-终止：锡 - 树脂材质：聚酯合金 - 配合界面间距：0.100英寸（2.54毫米） - 镀层最小厚度：配合（15微英寸/0.375微米），终止（75微英寸/1.875微米） - 操作温度范围：-40°C至+105°C - 终止界面样式：IDT或刺穿式

5. 功能详解： - 电气参数：每个接触点最大电流2A，最大电压250V。

6. 应用信息： - 产品系列：70431 - 产品家族：FFC/FPC连接器

7. 封装信息： - 封装类型：管装 - 堆叠：是 - PCB定位：无 - PCB保持：无 - 表面贴装兼容（SMC）：N/A
