15-80-0123

厂商：
MOLEX2
封装：
描述：
15-80-0123 - 2.54mm (.100) Pitch C-GridÂ® Header, Through Hole without Peg, Dual Row, Vertical, Shro...

数据手册：

下载15-80-0123.pdf

立即购买

详情介绍
数据手册
价格&库存

15-80-0123 数据手册

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015800123 Active cgrid__sl_products 2.54mm (.100") Pitch C-Grid® Header, Through Hole without Peg, Dual Row, Vertical, Shrouded, High Temperature, 12 Circuits, 0.38µm (15µ") Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-70567 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series Agency Certification UL E29179 General Product Family Series Application Overview Product Name PCB Headers 70567 Wire-to-Board cgrid__sl_products C-Grid® Physical Breakaway Circuits (Loaded) Circuits Detail Color - Resin First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB No 12 12 Black No 94V-0 No No None Yes Brass, Phosphor Bronze Gold Tin High Temperature Thermoplastic 2 Vertical 0.130 In 3.30 mm No Yes 0.093 In 2.40 mm Tube 0.100 In 2.54 mm 0.100 In 2.54 mm 15 0.375 75 1.875 Yes No Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Search Parts in this Series 70567Series Mates With 70450 Crimp Housing Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Fully No No -55°C to +105°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 2.5A 250V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 SMC & Wave Capable (TH only) 1 245 Material Info Old Part Number A-70567-0072 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0018 PS-70567 SDA-70567-**** This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-80-0123

1. 物料型号： - 型号：0015800123 - 状态：Active - 描述：2.54mm (.100") 间距 C-Grid® 插座，通孔无定位销，双排，垂直，带护罩，高温，12路，0.38µm (15µ") 金 (Au) 选择性电镀，锡 (Sn) PCB尾电镀。

2. 器件简介： - 产品名称：物理断开电路（带负载） - 电路细节：颜色 - 树脂，首次配合/最后断开，阻燃性能符合 Glow-Wire 标准，与配合件的配合指南，金属材质，电镀，配合件的电镀，尾端电镀，树脂数量：双排，PCB定位器，PCB保持，PCB厚度推荐值（英寸/毫米），包装类型，配合界面间距（英寸/毫米），电镀最小值：配合（微英寸/微米），电镀最小值：尾端（微英寸/微米）。

3. 引脚分配： - 引脚数量：12 - 引脚颜色：黑色 - 引脚材料：黄铜，磷青铜 - 引脚电镀：金，锡 - 引脚高温性能：是

4. 参数特性： - 阻燃等级：94V-0 - 是否有锁定机制：是 - 材料：金属 - 黄铜，磷青铜，电镀 - 金，锡，高温工程塑料 - 行数：2 - PCB尾长（英寸/毫米）：0.130/3.30 - PCB定位器：有 - PCB保持：有 - 推荐PCB厚度（英寸/毫米）：0.093/2.40 - 包装类型：管状 - 配合界面间距（英寸/毫米）：0.100/2.54 - 尾端电镀：金，锡

5. 功能详解： - 环境合规性：符合欧盟RoHS、中国RoHS、ELV和RoHS，REACH SVHC不含SVHC，无卤素状态未审核。 - 电气特性：最大电流每接触点2.5A，最大电压250V，无铅焊接过程数据，最大处理温度245°C。

6. 应用信息： - 与70450压接外壳配合使用。

7. 封装信息： - 封装规格：PK-70873-0018 - 产品规格：PS-70567 - 销售图纸：SDA-70567-
