15-91-2075

厂商：
MOLEX2
封装：
描述：
15-91-2075 - 2.54mm (.100) Pitch SLâ„¢ Wire-to-Board Header, Low Profile, Surface Mount, Single Row,...

数据手册：

下载15-91-2075.pdf

立即购买

详情介绍
数据手册
价格&库存

15-91-2075 数据手册

This document was generated on 04/09/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0015912075 Active 2.54mm (.100") Pitch SL™ Wire-to-Board Header, Low Profile, Surface Mount, Single Row, Right Angle, .120" Pocket, Shrouded, with Press-fit Plastic Peg, 7 Circuits, 0.38µm (15µ") Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-70400 (PDF) Product Specification PS-70541 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL LR19980 E29179 General Product Family Series Application Product Name PCB Headers 70634 Wire-to-Board SL™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Temperature Range - Operating Termination Interface: Style No 7 7 Black 50 94V-0 No Yes Brass, Phosphor Bronze Gold Tin High Temperature Thermoplastic 1 Right Angle Yes Yes 0.062 In 1.60 mm Tube 0.100 In 2.54 mm 15 0.375 75 1.875 Yes Yes Fully No -40°C to +105°C Surface Mount Search Parts in this Series 70634Series Mates With 70066n , 70066g , 70430g , 70400g Housing Electrical Current - Maximum per Contact 3A Voltage - Maximum 250V Solder Process Data Lead-free Process Capability Process Temperature max. C Reflow Capable (SMT only) 260 Material Info Old Part Number 70634-0041 Reference - Drawing Numbers Product Specification Sales Drawing PS-70400, PS-70541, RPS-70634-001 SDA-70634-**** This document was generated on 04/09/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-91-2075

1. 物料型号： - 型号：0015912075 - 状态：Active（活跃）

2. 器件简介： - 描述：2.54mm(.100") 间距 SLTM 线对板头，低轮廓，表面贴装排列，直角，.120" 口袋，带护套，配有压入式塑料钉，7路。 - 镀层：38um（15"）金（Au）选择性镀层，锡（Sn）PC尾镀层。

3. 引脚分配： - 电路（已加载）：7 - 电路（最大）：7

4. 参数特性： - 耐用性（最大插拔次数）：50次 - 阻燃等级：94V-0 - 材料 - 金属：黄铜，磷青铜 - 材料 - 镀层：金 - 材料 - 镀层终止：锡 - 材料 - 树脂：高温热塑性塑料 - 排数：1 - 定位方式：直角 - PCB定位：是 - PCB保持：是 - 推荐PCB厚度（英寸）：0.062 In - 推荐PCB厚度（毫米）：1.60 mm - 包装类型：管装 - 接口间距（英寸）：0.100 In - 接口间距（毫米）：2.54 mm - 镀层最小值：配合（uin）15，配合（um）0.375，终止（uin）75，终止（um）1.875 - 极化到配合部件：是 - 极化到PCB：是 - 护套：完全 - 可堆叠：否 - 工作温度范围：-40°C至+105°C - 终止接口样式：表面贴装

5. 功能详解： - 该器件为线对板连接头，具有低轮廓和直角设计，适用于表面贴装应用。具有7个电路，最大支持7个电路。采用高温热塑性塑料和黄铜材料，镀金和镀锡处理，以提高耐用性和可靠性。具有护套和极化设计，确保连接的稳定性和正确性。

6. 应用信息： - 产品家族：PCB头 - 系列：70634 - 应用：线对板 - 产品名称：SLTM

7. 封装信息： - 封装类型：表面贴装 - 电气特性：每个接触点最大电流3A
