15-97-7043

厂商：
MOLEX2
封装：
描述：
15-97-7043 - 4.20mm (.165) Pitch Mini-Fit TPAâ„¢ Header, Dual Row, Vertical, with Snap-in Plastic Pe...

数据手册：

下载15-97-7043.pdf

立即购买

详情介绍
数据手册
价格&库存

15-97-7043 数据手册

This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0015977043 Active minifit_tpa 4.20mm (.165") Pitch Mini-Fit TPA™ Header, Dual Row, Vertical, with Snap-in Plastic Peg PCB Lock, 4 Circuits, Tin (Sn) Plating, without Drain Holes Documents: 3D Model Drawing (PDF) Product Specification PS-5556-003 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 R72081037 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA TUV UL General Product Family Series Application Comments PCB Headers 30069 Wire-to-Board Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 Mini-Fit Plus HCS™ Crimp Terminal Crimpted to to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current de-rating information.. Square Pin, Solder Type, High Vibration Application minifit_tpa Mini-Fit TPA™ Overview Product Name Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) No 4 4 Black 30 No 94V-0 No No None Yes Brass Tin Tin Polyester 2 Vertical Yes Yes 0.070 In 1.80 mm Tray 0.165 In 4.20 mm 0.165 In 4.20 mm 35 Search Parts in this Series 30069Series Mates With 30067 Mini-Fit TPA™ Receptacle Housing Use With Mini-Fit TPA™ Receptacle Housing 30071 , 30072 Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style 0.90 35 0.90 Yes Yes Partial No No -40°C to +105°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 13A 600V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 Wave Capable (TH only) 1 235 Material Info Old Part Number 30069-08C1 Reference - Drawing Numbers Product Specification Sales Drawing PS-5556-003 SDA-30069-**** This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

15-97-7043

1. 物料型号： - 型号：0015977043 - 状态：Active - 描述：minifit_tpa，Peg PCB Lock, 4 Circuits, Tin (Sn) Plating, without Drain Holes

2. 器件简介： - 产品系列：Mini-Fit TPATM - 应用评论：最大电流13A每电路，当插座接合时 - 概述：适用于高振动应用的Mini-Fit TPATM

3. 引脚分配： - 电路数（已加载）：4 - 电路数（最大）：4

4. 参数特性： - 颜色 - 树脂：黑色 - 耐久性（最大插拔次数）：30 - 阻燃性：94V-0 - 针脚间距 - 接合界面（英寸）：0.165 In - 针脚间距 - 接合界面（毫米）：4.20 mm - 电镀最小值：接合（微英寸）：35 - 电镀最小值：接合（微米）：0.90

5. 功能详解： - 与30067 Mini-Fit TPA™插座壳体配合使用 - 与Mini-Fit TPA™插座壳体30071、30072配合使用

6. 应用信息： - 产品家族：PCB Headers - 系列：Wire-to-Board - 电流 - 每个接点最大：13A - 电压 - 最大：600V

7. 封装信息： - 包装类型：Tray - 极化到配合件：是 - 极化到PCB：是 - 部分屏蔽：是 - 堆叠：否 - 表面安装兼容（SMC）温度范围 - 运行：否 -40°C至+105°C - 终止接口：样式 - 通孔
