16-02-0105

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0016020105 Active cgrid__sl_products SL™ Crimp Terminal, Series 70021, Male, with Tin (Sn) Plated Contact, 24-30 AWG, Reel Documents: Drawing (PDF) Product Specification PS-70021 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only Crimp Terminals 70021 Yes cgrid__sl_products SL™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Series General Product Family Series Crimp Quality Equipment Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Phosphor Bronze Tin Tin Reel 150 3.75 75 1.875 Crimp or Compression 1.52mm (.060") max. 24, 26, 28, 30 N/A Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Material Info Old Part Number 70021-0004 Search Parts in this Series 70021Series Use With 70066 Housing, 70107 Housing Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # FineAdjust™ 0639014500 Applicator for SL™ Crimp Terminal, Male, 22 AWG, 41 Strands/44 AWG Wire Hand Crimp Tool, UL 0638118800 Approved T2 Terminator 0639103400 Tooling Die Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-1300 PS-70021 SD-70021-0*04_0*21, SD-70021-0004 FineAdjust™ 0639003400 Applicator for SL™ Male Crimp Terminal, 24-30 AWG Insertion Tool 0011020022 Extraction Tool 0011030036 Japan Description Product # Applicator for M211A 0570173000 Bench Press, 22-30 AWG, for 70021 Crimp Terminal Hand Insertion Tool 0570336000 This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
