16-02-0108

厂商：
MOLEX2
封装：
描述：
16-02-0108 - SLâ„¢ Crimp Terminal, Series 70021, Male, with Tin (Sn) Plated Contact, 24-30 AWG, Bag ...

数据手册：

下载16-02-0108.pdf

立即购买

详情介绍
数据手册
价格&库存

16-02-0108 数据手册

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0016020108 Active cgrid__sl_products SL™ Crimp Terminal, Series 70021, Male, with Tin (Sn) Plated Contact, 24-30 AWG, Bag Documents: Drawing (PDF) Product Specification PS-70021 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only Crimp Terminals 70021 Yes cgrid__sl_products SL™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Series General Product Family Series Crimp Quality Equipment Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Phosphor Bronze Tin Tin Bag 150 3.75 75 1.875 Crimp or Compression 1.52mm (.060") max. 24, 26, 28, 30 N/A Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Material Info Old Part Number 70021-0204 Search Parts in this Series 70021Series Use With 70066 Housing, 70107 Housing Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool, UL 0638118800 Approved Insertion Tool 0011020022 Extraction Tool 0011030036 Japan Description Product # Hand Crimp Tool 0570365000 Hand Crimp Tool 0570375000 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0822 PS-70021 SD-70021-0*04_0*21, SD-70021-0204 This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

16-02-0108

1. 物料型号： - 型号：0016020108 - 状态：Active（活跃） - 描述：SL™ Crimp Terminal, Series 70021, Male, with Tin (Sn) Plated Contact, 24-30 AWG, Bag（SL™ 压接端子，70021系列，公头，锡（Sn）镀层接触，24-30 AWG，袋装）

2. 器件简介： - 产品名称：SL™ Crimp Terminals 70021 - 材料：Phosphor Bronze（磷青铜） - 镀层：Tin（锡） - 包装类型：Bag（袋装）

3. 引脚分配： - 该端子适用于24-30 AWG的绞合线，最大绝缘外径为1.52mm（0.060"）。

4. 参数特性： - 镀层：最小镀锡层厚度为0.000150英寸（3.75微米）覆盖在镍层上。 - 线径：适用于24 AWG至30 AWG的线径。

5. 功能详解： - 该端子设计用于与70066和70107系列的外壳配合使用。 - 端子形状为公头压接或压缩式。

6. 应用信息： - 适用于绞合线，最大绝缘外径为1.52mm（0.060"）。 - 需要参考Molex的操作和服务手册以获取详细信息。

7. 封装信息： - 包装规格：PK-70873-0822 - 产品规格：PS-70021 - 销售图纸：SD-70021-004_021, SD-70021-0204
