16-02-0109

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0016020109 Active cgrid__sl_products SL™ Crimp Terminal, Series 70021, Male, with 0.38µm (15µ") Selective Gold (Au) Plated Contact, 24-30 AWG, Bag Documents: Drawing (PDF) Product Specification PS-70021 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only Crimp Terminals 70021 Yes cgrid__sl_products SL™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Series General Product Family Series Crimp Quality Equipment Overview Product Name Physical Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Male Phosphor Bronze Gold Tin Bag 15 0.375 75 1.875 Crimp or Compression 1.52mm (.060") max. 24, 26, 28, 30 N/A Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Material Info Old Part Number 70021-0206 Search Parts in this Series 70021Series Use With 70066 Housing, 70107 Housing Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool, UL 0638118800 Approved Insertion Tool 0011020022 Extraction Tool 0011030036 Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0822 PS-70021 SD-70021-0206 This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
