22-02-3243

This document was generated on 06/04/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0022023243 Active 2.54mm (.100") Vertical, Non-ZIF, Low Profile Receptacle, 24 Circuits Agency Certification UL E29179 General Product Family Series Overview Product Name FFC/FPC Connectors 5229 ffc_fpc_throughhole N/A EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Circuits (Loaded) Contact Position Entry Angle Flammability Mated Height (in) Mated Height (mm) Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to PCB Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Wire/Cable Type 24 N/A Vertical 94V-0 0.256 In 6.50 mm 1 Vertical 0.142 In 3.60 mm None Tray 0.100 In 2.54 mm No No No -40°C to +105°C Through Hole FFC/FPC Search Parts in this Series 5229Series Electrical Current - Maximum per Contact Voltage - Maximum 0.5A, 1A 200V Material Info Old Part Number 5229-24CPB Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing SPK-5229-001 PS-5229-001, PS-5229-002, PS-5229-005, PS-5229-006, PS-5229-007 SD-5229-NCPB This document was generated on 06/04/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
