22-03-2091

This document was generated on 04/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0022032091 Active 2.54mm (.100") Pitch KK® Wire-to-Board Header, Single Row, Vertical, 9 Circuits, PA Polyamide Nylon, Tin (Sn) Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-10-07 (PDF) RoHS Certificate of Compliance (PDF) Series Agency Certification CSA UL LR19980 E29179 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Product Name PCB Headers 4030 Board-to-Board, Wire-to-Board KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Lock to Mating Part Material - Metal Material - Plating Mating Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 9 9 Natural (White) 25 94V-0 No None Brass Tin Nylon 1 Vertical 0.135 In 3.43 mm No None 0.062 In 1.60 mm Bag 0.100 In 2.54 mm 200 5.00 No No No Yes No 0°C to +75°C Through Hole Search Parts in this Series 4030Series Mates With 2695 , 6471 , 7880 , 4455 , 7720 Electrical Current - Maximum per Contact Voltage - Maximum 4A 250V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 Wave Capable (TH only) 1 235 Material Info Old Part Number A-4030-09A102 Reference - Drawing Numbers Product Specification Sales Drawing PS-10-07 SDA-4030 This document was generated on 04/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
