22-03-5145

This document was generated on 05/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0022035145 Active 2.50mm (.098") Pitch SPOX™ Wire-to-Board Header, Vertical, Shrouded, 14 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-5264-001 (PDF) RoHS Certificate of Compliance (PDF) Series LR19980 E29179 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Product Name PCB Headers 5267 Wire-to-Board SPOX™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Lock to Mating Part Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style No 14 14 Natural 30 94V-0 No Yes Tin Tin Nylon 1 Vertical 0.138 In 3.50 mm No Yes 0.062 In 1.60 mm Bag 0.098 In 2.50 mm 160 4 160 4 Yes No Fully No No -40°C to +105°C Through Hole Search Parts in this Series 5267Series Mates With 5264 , 42219 Electrical Current - Maximum per Contact 3A Voltage - Maximum 250V Material Info Old Part Number 5267-14A Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing SPK-5267-001 PS-5264-001, RPS-5264-005, RPS-5267-001 SD-5267-NA This document was generated on 05/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
