22-05-1062

This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0022051062 Active 2.50mm (.098") Pitch Wire-to-Board Header, Right Angle, Friction Lock, 6 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-5046-002 (PDF) Product Specification PS-5102-002 (PDF) Product Specification PS-51191-002 (PDF) Product Specification PS-5251-001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only Agency Certification CSA TUV UL LR19980 R72090224 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application MolexKits Product Name PCB Headers 5046 Wire-to-Board Yes N/A Physical Breakaway Circuits (Loaded) Circuits (maximum) Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) No 6 6 30 No 94V-0 No No None Yes Brass Tin Tin 1 Right Angle 0.134 In 3.40 mm No None 0.062 In 1.60 mm Bag 0.098 In 2.50 mm 200 5 200 5 No Partial No No Search Parts in this Series 5046Series Mates With 51191 KK® Wire-to-Board Header Temperature Range - Operating Termination Interface: Style -40°C to +105°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 1.5A, 2.5A, 2A, 3A 250V Material Info Old Part Number 5046-06A Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing SPK-5046-001 PS-5046-002, PS-5102-002, PS-51191-002, PS-5251-001, RPS-51191-007 SD-5046-NA This document was generated on 05/27/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
