22-05-1102

厂商：
MOLEX2
封装：
描述：
22-05-1102 - 2.50mm (.098) Pitch Wire-to-Board Header, Right Angle, Friction Lock, 10 Circuits, Tin ...

数据手册：

下载22-05-1102.pdf

立即购买

详情介绍
数据手册
价格&库存

22-05-1102 数据手册

This document was generated on 05/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0022051102 Active 2.50mm (.098") Pitch Wire-to-Board Header, Right Angle, Friction Lock, 10 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-5046-002 (PDF) Product Specification PS-5102-002 (PDF) Product Specification PS-51191-002 (PDF) Product Specification PS-5251-001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only Agency Certification CSA TUV UL LR19980 R72090224 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Product Name PCB Headers 5046 Wire-to-Board N/A Physical Breakaway Circuits (Loaded) Circuits (maximum) Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Surface Mount Compatible (SMC) Temperature Range - Operating No 10 10 30 No 94V-0 No No None Yes Brass Tin Tin 1 Right Angle 0.134 In 3.40 mm No None 0.062 In 1.60 mm Bag 0.098 In 2.50 mm 200 5 200 5 No Partial No No -40°C to +105°C Search Parts in this Series 5046Series Mates With 51191 KK® Wire-to-Board Header Termination Interface: Style Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 1.5A, 2.5A, 2A, 3A 250V Material Info Old Part Number 5046-10A Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing SPK-5046-001 PS-5046-002, PS-5102-002, PS-51191-002, PS-5251-001, RPS-51191-007 SD-5046-NA This document was generated on 05/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

22-05-1102

1. 物料型号： - 型号：0022051102 - 状态：Active（活跃）

2. 器件简介： - 描述：2.50mm (.098") 间距，板对线直角头，摩擦锁，10路，镀锡（Sn）。

3. 引脚分配： - 路数（已装载）：10 - 最大路数：10

4. 参数特性： - 耐用性（最大插拔次数）：30次 - 阻燃等级：94V-0 - 金属材质：黄铜 - 镀层：镀锡，最小厚度为2um（um） - 排列：单排 - 引脚间距：2.50mm（0.098英寸） - PCB推荐厚度：1.60mm（0.062英寸） - 工作温度范围：-40°C至+105°C

5. 功能详解： - 该器件为Wire-to-Board应用，具有10个电路，最大电流1.5A至3A不等，最大电压250V。

6. 应用信息： - 产品家族：PCB Headers - 系列：5046 - 应用：Wire-to-Board

7. 封装信息： - 封装类型：直角 - 包装类型：袋装 - 部分可与51191系列的KK® Wire-to-Board Header配合使用。
