22-12-4082

This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0022124082 Active kk 2.54mm (.100") Pitch KK® Wire-to-Board Header, Right Angle, with Friction Lock, 8 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0088 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Overview Product Name PCB Headers 7395 Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Temperature Range - Operating No 8 8 Natural (White) 100 No 94V-0 No No None Yes Brass Gold Gold Nylon 1 Right Angle 0.150 In 3.80 mm No None 0.062 In 1.60 mm Bag 0.100 In 2.54 mm 20 0.5 20 0.5 Yes Partial No 0°C to +75°C Search Parts in this Series 7395Series Mates With 2695 KK® Crimp Terminal Housing. 6471 KK® Crimp Terminal Housing. 7720 KK® IDT Double Cantilever Termination Interface: Style Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 4A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 739508BG Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-7478-001 PS-99020-0088 SD-7395-001 This document was generated on 05/24/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
