040-06-2005

This document was generated on 03/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0040062005 Active Panel Grounding Clip Crimp Terminal 42172, 16-18 AWG, 301 Stainless Steel, 1.27mm (.050") Panel Thickness Documents: 3D Model Drawing (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR19980 E126412 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Comments Crimp Quality Equipment Product Name Crimp Terminals 42172 (2) 18 AWG, or (1) 18 and (1) 16 AWG Yes Panel Grounding Clip Physical Gender Material - Metal Material - Plating Mating Packaging Type Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Stainless Steel Unplated Reel Crimp or Compression 3.00mm (.118") max 16, 18 N/A Material Info Old Part Number 42172B1 Search Parts in this Series 42172Series SD-42172-** Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Mini-Mac™ 0638913000 Applicator Reference - Drawing Numbers Sales Drawing This document was generated on 03/11/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
