22-44-6104

厂商：
MOLEX3
封装：
描述：
22-44-6104 - 2.5 HEADER ASSY 100 - Molex Electronics Ltd.

数据手册：

下载22-44-6104.pdf

立即购买

详情介绍
数据手册
价格&库存

22-44-6104 数据手册

This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: Documents: 3D Model Drawing (PDF) 0022446104 Active 2.5 HEADER ASSY 100 Product Specification PS-42219-0001 (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR19980 E29179 image - Reference only EU RoHS China RoHS Compliance Status Not Reviewed REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series General Product Family Series Comments Crimp Quality Equipment Product Name IDT and Solder Connectors 42219 Spring Box|Use with 24 AWG solid Yes SPOX™ Physical Circuits (Loaded) Durability (mating cycles max) Flammability Gender Glow-Wire Compliant Lock to Mating Part Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Stackable Temperature Range - Operating Wire Size AWG 10 25 94V-0 Female No None 1 Bag No 0.098 In 2.50 mm No 0°C to +75°C 24, 26 Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Search Parts in this Series 42219Series Mates With Headers, 5267 , 42249 , 42267 , 5268 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # IDT - Manual Press 0011219757 Hawk™ Discrete 0623000500 Wire Terminator Machine 2.5mm Hawk™ Discrete 0623000700 Wire Terminator Machine 2.5mm Changehead 0690080290 for Parallel Action Handtool Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Material Info Reference - Drawing Numbers Product Specification Sales Drawing PS-42219-0001 SDA-42219-* 69008-0949 for 2.5mm User Friendly This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

22-44-6104

1. 物料型号： - 型号：0022446104 - 状态：Active（活跃）

2. 器件简介： - 描述：2.5 HEADER ASSY 100（2.5mm头座组件100） - 产品家族：IDT和焊锡连接器 - 系列：42219 - 评论：弹簧盒，适用于24 AWG实心线 - 产品名称：SPOX™

3. 引脚分配： - 电路（已加载）：10 - 引脚数：1排

4. 参数特性： - 耐久性（最大插拔次数）：25次 - 阻燃性：94V-0 - 性别：Female（母头） - 热丝合规性：否 - 锁紧至配合部件：无 - 间距 - 配合界面（英寸）：0.098英寸 - 间距 - 配合界面（毫米）：2.50毫米 - 堆叠：否 - 工作温度范围：0°C至+75°C - 线规AWG：未提供具体数值

5. 功能详解： - 该连接器支持10个电路，最大插拔次数为25次，具有94V-0的阻燃等级，适用于0°C至+75°C的工作温度范围。

6. 应用信息： - 配合使用的头座型号：5267、42249、42267、5268 - 应用工具：IDT - 手动压机（0011219757）、Hawk™离散（0623000500）、2.5mm Hawk™离散更换头（0690080290）、Action手动工具等。

7. 封装信息： - 封装类型：袋装
