22-50-3105

厂商：
MOLEX3
封装：
描述：
22-50-3105 - 2.54mm (.100") KK IDT Double Cantilever Contact, 10 Circuits, Tin (Sn) - Molex Electron...

数据手册：

下载22-50-3105.pdf

立即购买

详情介绍
数据手册
价格&库存

22-50-3105 数据手册

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0022503105 Active kk 2.54mm (.100") KK® IDT Double Cantilever Contact, 10 Circuits, Tin (Sn), FeedThrough, Friction Ramp and Polarizing Rib, Green ID Strip Documents: 3D Model Drawing (PDF) Product Specification PSX-7690S (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification UL General Product Family Series Comments Crimp Quality Equipment Overview Product Name IDT and Solder Connectors 7720 Version H Yes kk KK® Physical Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Gender Glow-Wire Compliant Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Polarized to Mating Part Stackable Temperature Range - Operating Termination Interface: Style Wire Size AWG 10 10 Natural 5 94V-2 Female No None Brass Tin Tin Nylon 1 Bag No 0.100 In 2.54 mm 0.100 In 2.54 mm Yes No 0°C to +50°C IDT or Pierce 24 Stranded, 26 Solid, 26 Stranded Topcoat Search Parts in this Series 7720Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Insertion Tool for 0638133504 2.54mm (.100") Pitch KK® IDT Crimp Terminals IDT - Semi-automatic 0011200412 - Bench-Top Terminator Electrical Current - Maximum per Contact Voltage - Maximum 4A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 7720SC10H Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-7720-100 PSX-7690S SDA-7720S-*N* This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

22-50-3105

1. 物料型号： - 型号：0022503105 - 状态：Active（活跃）

2. 器件简介： - 描述：2.54mm (.100") KK® IDT Double Cantilever Contact, 10 Circuits, Tin (Sn), Feed-Through, Friction Ramp and Polarizing Rib, Green ID Strip（2.54mm (.100") KK® IDT双悬臂接触，10回路，锡（Sn），穿透式，摩擦坡道和极化肋，绿色ID条） - 文档：3D模型图纸（PDF）、产品规格PSX-7690S（PDF）、RoHS合规证书（PDF）

3. 引脚分配： - 回路（已加载）：10 - 回路（最大）：10 - 极化到配对部分：是

4. 参数特性： - 颜色 - 树脂：自然色 - 耐用性（最大插拔次数）：5 - 阻燃性：94V-2 - 性别：女 - 锁到配对部分：无 - 材料 - 金属：黄铜 - 材料 - 镀层配对：锡 - 材料 - 镀层终止：锡 - 材料 - 树脂：尼龙 - 行数：1 - 包装类型：袋装 - 面板安装：否 - 间距 - 配对接口（英寸）：0.100 In - 间距 - 配对接口（毫米）：2.54 mm - 间距 - 终止接口（英寸）：0.100 In - 间距 - 终止接口（毫米）：2.54 mm - 堆叠：否 - 操作温度范围：0°C至+50°C - 终止接口：IDT或刺穿式 - 线规AWG：24股线，26实心，26股线顶层涂层

5. 功能详解： - 电气特性： - 每个接触点最大电流：4A - 最大电压：250V - 焊接工艺数据： - 无铅工艺能力：波峰焊（仅限TH）

6. 应用信息： - 产品家族：IDT和焊接连接器 - 系列：7720 - 旧型号：7720SC10H

7. 封装信息： - 封装类型：袋装
