22-50-3285

厂商：
MOLEX3
封装：
描述：
22-50-3285 - 2.54mm (.100") KK® IDT Double Cantilever Contact, 28 Circuits, Tin (Sn) - Molex Electro...

数据手册：

下载22-50-3285.pdf

立即购买

详情介绍
数据手册
价格&库存

22-50-3285 数据手册

This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0022503285 Active kk 2.54mm (.100") KK® IDT Double Cantilever Contact, 28 Circuits, Tin (Sn), FeedThrough, Friction Ramp and Polarizing Rib, Green ID Strip Documents: 3D Model Drawing (PDF) Product Specification PSX-7690S (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only IDT and Solder Connectors 7720 Version H Yes kk KK® EU RoHS China RoHS Compliance Status Not Reviewed REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Comments Crimp Quality Equipment Overview Product Name Physical Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Gender Glow-Wire Compliant Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Polarized to Mating Part Stackable Temperature Range - Operating Termination Interface: Style Wire Size AWG 28 28 Natural 5 Female No None Brass Tin Tin Nylon 1 Bag 0.100 In 2.54 mm 0.100 In 2.54 mm Yes No 0°C to +75°C IDT or Pierce 24 Stranded, 26 Solid, 26 Stranded Topcoat Search Parts in this Series 7720Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Insertion Tool for 0638133504 2.54mm (.100") Pitch KK® IDT Crimp Terminals IDT - Semi-automatic 0011200412 - Bench-Top Terminator Electrical Current - Maximum per Contact Voltage - Maximum 4A 250V Material Info Old Part Number 7720SC28H Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-7720-100 PSX-7690S SDA-7720S-*N* This document was generated on 05/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

22-50-3285

1. 物料型号： - 型号：0022503285 - 状态：Active（有效）

2. 器件简介： - 描述：2.54mm (.100") KK® IDT双悬臂接触，28路，锡（Sn）镀层，送料。 - 概述：KK®系列7720，物理上最大28路电路（Loaded），自然色树脂，最大5次耐用性（配对周期），雌性，无极性，无锁定到配对部分，金属材质为黄铜，镀层材质为锡，树脂材质为尼龙，非堆叠，操作温度范围0°C至+75°C，IDT或刺穿式终止接口，电线规格为AWG 24股线，26实心线，26股线顶层涂层。

3. 引脚分配： - 提供了不同引脚数量下的引脚配置和尺寸信息，从2到28引脚的详细配置。

4. 参数特性： - 电气参数：每个接触最大电流4A，最大电压250V。 - 旧型号：7720SC28H - 包装规格参考：PK-7720-100

5. 功能详解： - 提供了详细的产品规格和销售图纸信息，如PSX-7690S和SDA-7720S-N。

6. 应用信息： - 该产品为IDT和焊锡连接器，适用于2.54mm（.100"）间距的KK®IDT压接端子。

7. 封装信息： - 封装类型：袋装。 - 引脚间距：配对接口为0.100英寸（2.54mm），终止接口为0.100英寸（2.54mm）。 - 极性：与配对部分极性匹配。 - 材料：金属材质为黄铜，镀层为锡。
