25-02-2012

厂商：
MOLEX3
封装：
描述：
25-02-2012 - 2.54mm (.100") Pitch C-Grid Header, Dual Row, Shrouded, with PC Slot and Guide Ear, 12 ...

数据手册：

下载25-02-2012.pdf

立即购买

详情介绍
数据手册
价格&库存

25-02-2012 数据手册

This document was generated on 04/09/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0025022012 Active 2.54mm (.100") Pitch C-Grid® Header, Dual Row, Shrouded, with PC Slot and Guide Ear, 12 Circuits, Tn (Sn) Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-70204 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Application Product Name PCB Headers 70204 Board-to-Board C-Grid® Physical Breakaway Circuits (Loaded) Circuits (maximum) Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Temperature Range - Operating Termination Interface: Style No 12 12 25 94V-0 No Yes None Brass, Phosphor Bronze Tin Tin 2 Vertical 0.110 In 2.79 mm No None Tray 0.100 In 2.54 mm 150 3.81 150 3.81 Yes No Fully No -40°C to +105°C Through Hole Search Parts in this Series 70204Series Mates With 71973 Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Solder Process Data Duration at Max. Process Temperature (seconds) Lead-free Process Capability Max. Cycles at Max. Process Temperature Process Temperature max. C 5 Wave Capable (TH only) 1 235 Material Info Old Part Number 70204-0389 Reference - Drawing Numbers Product Specification Sales Drawing PS-70204 SDA-70204-0385-0448 This document was generated on 04/09/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

25-02-2012

1. 物料型号： - 型号：0025022012 - 状态：Active

2. 器件简介： - 描述：2.54mm (.100") Pitch C-Grid@ Header, Dual Row, Shrouded Ear, 12 Circuits, Tin (Sn) Plating - 产品家族：PCB Headers - 系列：70204 - 应用：Board-to-Board - 产品名称：C-GridR

3. 引脚分配： - 引脚数量（已加载）：12 - 最大引脚数量：12

4. 参数特性： - 耐用性（最大配对周期）：25 - 阻燃性：94V-0 - 极化：是，对于配对部分 - 堆叠：否 - 操作温度范围：-40°C至+105°C - 电气参数： - 每接触最大电流：3A - 最大电压：250V

5. 功能详解： - 无断路器 - 完全遮蔽 - 通过孔式端接界面 - 材料-金属：黄铜，磷青铜 - 材料-配对镀层：锡 - 材料-终止镀层：锡

6. 应用信息： - 应用：板对板连接

7. 封装信息： - 行数：2 - 包装类型：Tray - 配对接口间距：2.54mm（0.100英寸） - 镀层最小厚度：配对（3.81微米/150微英寸），终止（3.81微米/150微英寸）
