26-01-1098

This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0026011098 Active 3.96mm (.156") Pitch Board-to-Board Receptacle, Bottom Entry, 9 Circuits Documents: 3D Model Drawing (PDF) Product Specification PS-5145-003 (PDF) Product Specification PS-5145-006 (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA TUV UL LR19980 R72090224 E29179 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Product Name PCB Receptacles 5145 Board-to-Board N/A Physical Circuits (Loaded) Durability (mating cycles max) Flammability Glow-Wire Compliant Keying to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Number of Rows Orientation PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Polarized to PCB Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style 9 30 94V-2 No Yes Brass Tin Tin 1 Bottom Entry No None 0.062 In 1.60 mm Bag 0.156 In 3.96 mm Yes No -40°C to +105°C Through Hole Search Parts in this Series 5145Series Mates With 2461 Electrical Current - Maximum per Contact Voltage - Maximum 5A 250V Material Info Old Part Number 5145-09BH Reference - Drawing Numbers Product Specification Sales Drawing PS-5145-003, PS-5145-006 SD-5145-001, SD-5145-NBH This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
