26-11-6145

厂商：
MOLEX3
封装：
描述：
26-11-6145 - 3.96mm (.156") Pitch KK® PC Board Connector, Top Entry, Nylon Connector, 1.0μm (40μ") T...

数据手册：

下载26-11-6145.pdf

立即购买

详情介绍
数据手册
价格&库存

26-11-6145 数据手册

This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0026116145 Active kk 3.96mm (.156") Pitch KK® PC Board Connector, Top Entry, Nylon Connector, 1.0µm (40µ") Tin (Sn), 14 Circuits Documents: Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series General Product Family Series Application Comments Overview Product Name PCB Receptacles 3215 Board-to-Board Lock between 5&6 and 9&10 Circuit kk KK® image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Stackable Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style 14 14 Natural 25 No No Yes Yes Phosphor Bronze Tin Tin Nylon 1 Vertical 0.161 In 4.10 mm No None 0.062 In 1.57 mm Bag 0.156 In 3.96 mm 0.156 In 3.96 mm 40.00 1.000 40.00 1.00 Yes No No No 0°C to +50°C Through Hole Search Parts in this Series 3215Series Mates With 03190 , 03192 Electrical Current - Maximum per Contact Grounding to PCB Voltage - Maximum 4.5A No 250V Material Info Old Part Number 3215HR14BB Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3215-**N**-** This document was generated on 06/08/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

26-11-6145

1. 物料型号： - 型号：0026116145 - 状态：Active（活跃）

2. 器件简介： - 描述：3.96mm（.156"）间距KK®PCB板连接器，顶部进入，尼龙连接器，1.0µm（40µ"）锡（Sn），14电路。 - 产品系列：3215 - 应用：板对板（Board-to-Board）

3. 引脚分配： - 电路（最大）：14 - 行数：1

4. 参数特性： - 颜色 - 树脂：自然色 - 耐久性（最大插拔次数）：25 - 灼热丝合规性：否 - 与配对部分的钥匙配合：是 - 与配对部分的锁定：是 - 金属材质：磷青铜 - 镀层 - 配合：锡 - 镀层 - 终止：锡 - 树脂材质：尼龙 - PCB厚度推荐（mm）：1.57 - 配合界面间距（mm）：3.96 - 镀层最小厚度（um）：1.00

5. 功能详解： - 极化到配对部分：是 - 极化到PCB：否 - 堆叠：否 - 表面安装兼容（SMC）：否 - 工作温度范围：0°C至+50°C - 终止接口样式：通孔

6. 应用信息： - 与03190、03192配合使用 - 最大电流每接触点：4.5A - 接地到PCB的最大电压：250V

7. 封装信息： - 包装类型：袋装 - PCB尾长（mm）：4.10 - PCB定位：无 - PCB保持：无
