26-19-2171

厂商：
MOLEX3
封装：
描述：
26-19-2171 - 3.96mm (.156") Pitch KK Wire-to-Board Header, Vertical, Round Pin, with Polarizing Wall...

数据手册：

下载26-19-2171.pdf

立即购买

详情介绍
数据手册
价格&库存

26-19-2171 数据手册

This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0026192171 Active kk 3.96mm (.156") Pitch KK® Wire-to-Board Header, Vertical, Round Pin, with Polarizing Wall, 17 Circuits, Tin (Sn) Plating Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only LR19980 R72090224 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA TUV General Product Family Series Application Overview Product Name PCB Headers 3190 Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to PCB Shrouded Stackable Temperature Range - Operating No 17 17 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.175 In 4.45 mm No None 0.062 In 1.60 mm Bag 0.156 In 3.96 mm 200 5 200 5 No Partial No 0°C to +75°C Search Parts in this Series 3190Series Mates With 3069 KK® Crimp Terminal Housing. 3215 KK® PC Board Connector Termination Interface: Style Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Material Info Old Part Number 319017A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3190-N** This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

26-19-2171

1. 物料型号： - 型号：0026192171 - 状态：Active（活跃）

2. 器件简介： - 描述：3.96mm（.156"）间距KK®线对板头，垂直，圆针，带极化壁，17电路，锡（Sn）镀层。

3. 引脚分配： - 电路（已加载）：17 - 电路（最大）：17

4. 参数特性： - 颜色 - 树脂：自然色 - 耐久性（最大插拔次数）：25次 - 阻燃性：94V-2 - 金属材质：黄铜 - 镀层 - 插接：锡 - 镀层 - 终止：锡 - 树脂材质：尼龙 - 行数：1 - 取向：垂直 - PCB尾长（英寸）：0.175 In - PCB尾长（毫米）：4.45 mm - PCB厚度推荐（英寸）：0.062 In - PCB厚度推荐（毫米）：1.60 mm - 间距 - 插接界面（英寸）：0.156 In - 间距 - 插接界面（毫米）：3.96 mm - 镀层最小：插接（微英寸）：200 - 镀层最小：插接（微米）：5 - 镀层最小：终止（微英寸）：200 - 镀层最小：终止（微米）：5 - 操作温度范围：0°C至+75°C

5. 功能详解： - 该产品为线对板头，适用于电线与PCB板的连接。

6. 应用信息： - 产品家族：PCB头 - 系列：3190 - 应用：线对板 - 产品名称：KKR

7. 封装信息： - 包装类型：袋装 - 极化到PCB：否 - 部分封闭：是 - 可堆叠：否
